SLIDE RAIL AND TRACK ASSEMBLY для Arctic Cat Z 370 (USA) - 2000 года выпуска

  • №
    Артикул
    Название
  • -
    7994-355 COMPLETE SKID FRAME ASSEMBLY
    COMPLETE SKID FRAME ASSEMBLY
  • 1
    0704-344 RAIL, SLIDE, FORMED
    RAIL, SLIDE, FORMED
  • 2
    0604-426 SUPPORT, RAIL
    SUPPORT, RAIL
  • 3
    8040-366 NUT, LOCK
    NUT, LOCK
  • 4
    8050-217 WASHER
    WASHER
  • 5
    0604-231 END CAP, SLIDE RAIL
    END CAP, SLIDE RAIL
  • 6
    8002-044 SCREW, CAP
    SCREW, CAP
  • 7
    0123-869 SCREW, MACHINE
    SCREW, MACHINE
  • 8
    0604-640 WEARSTRIP, SLIDE RAIL (BLACK)
    WEARSTRIP, SLIDE RAIL (BLACK)
  • 9
    8012-132 SCREW, CAP
    SCREW, CAP
  • 10
    0104-631 PAD, SHOCK
    PAD, SHOCK
  • 11
    0123-767 RIVET, SOLID
    RIVET, SOLID
  • 12
    0423-090 NUT, PUSH
    NUT, PUSH
  • 13
    0604-152 SPACER AXLE HOUSING (REAR)
    SPACER AXLE HOUSING (REAR)
  • 14
    8002-134 SCREW, CAP
    SCREW, CAP
  • 15
    8040-426 NUT, LOCK
    NUT, LOCK
  • 16
    0602-868 TRACK ASSEMBLY (INC. 17, 18)
    TRACK ASSEMBLY (INC. 17, 18)
  • 17
    0602-488 . CLIP, GUIDE
    . CLIP, GUIDE
  • 18
    0602-541 . CLIP, WEAR
    . CLIP, WEAR
