CYLINDER HEAD AND CAMSHAFT/VALVE ASSEMBLY для Arctic Cat ALTERRA 300 GREEN - 2017 года выпуска`
-
№АртикулНазвание
-
-3306-895 COMPLETE ENGINE ASSEMBLYCOMPLETE ENGINE ASSEMBLY
-
13303-360 BOLT FLANGE 6X25BOLT FLANGE 6X25
-
23305-608 COVER, CYLINDER HEADCOVER, CYLINDER HEAD
-
33305-609 GASKETGASKET
-
43305-618 PLATE, STOPPLATE, STOP
-
53304-026 NUT, TAPPET ADJUSTINGNUT, TAPPET ADJUSTING
-
63304-007 SCREW, TAPPET ADJUSTINGSCREW, TAPPET ADJUSTING
-
73305-611 ARM, ROCKERARM, ROCKER
-
83304-668 NUT, LOCKNUT, LOCK
-
93304-048 WASHER - 8 MMWASHER - 8 MM
-
103305-689 HOLDER, CAMSHAFTHOLDER, CAMSHAFT
-
113303-674 SHAFT, ROCKER ARM - INTAKESHAFT, ROCKER ARM - INTAKE
-
123305-612 SHAFT, ROCKER ARM - EXHAUSTSHAFT, ROCKER ARM - EXHAUST
-
133305-613 CAMSHAFTCAMSHAFT
-
140217-730 PLUG, SPARK (DPR7EA-9)PLUG, SPARK (DPR7EA-9)
-
153303-342 PIN, DOWELPIN, DOWEL
-
163303-044 COTTER, VALVECOTTER, VALVE
-
173303-042 RETAINER, VALVE SPRINGRETAINER, VALVE SPRING
-
183303-682 SPRING, VALVE - OUTERSPRING, VALVE - OUTER
-
193303-683 SPRING, VALVE - INNERSPRING, VALVE - INNER
-
203303-043 SEAT, VALVE SPRINGSEAT, VALVE SPRING
-
213303-657 SEAL, VALVE STEMSEAL, VALVE STEM
-
223305-615 VALVE, EXHAUSTVALVE, EXHAUST
-
233305-614 VALVE, INTAKEVALVE, INTAKE
-
243307-084 NUTNUT
-
253305-616 FLANGE, INTAKE (INC. 26)FLANGE, INTAKE (INC. 26)
-
263304-620 ...O-RING...O-RING
-
273304-114 BOLT, STUDBOLT, STUD
-
283305-617 HEAD, CYLINDER (INC. 29)HEAD, CYLINDER (INC. 29)
-
293303-656 ...BOLT, SEALING - 12 MM...BOLT, SEALING - 12 MM
-
303304-918 BOLT FLANGE SH M6X1.0X110BOLT FLANGE SH M6X1.0X110
-
313304-049 WASHERWASHER
-
323303-249 BOLT, STUDBOLT, STUD
-
333303-659 GASKET, CYLINDER HEADGASKET, CYLINDER HEAD
-
343305-621 CYLINDERCYLINDER
-
353305-461 GASKET, CYLINDERGASKET, CYLINDER
-
363304-157 CLAMP, ROUTINGCLAMP, ROUTING
-
373305-410 CLAMP, INTAKE FLANGECLAMP, INTAKE FLANGE
