DRIVE TRAIN ASSEMBLY для Arctic Cat TRV 1000 XT L7E RED [A2016TGW1P7EE] - 2016 года выпуска

  • №
    Артикул
    Название
  • 1
    2502-110 GEARCASE, FRONT
    GEARCASE, FRONT
  • 2
    1402-620 BLADDER, CASE
    BLADDER, CASE
  • 3
    0423-315 CLAMP, HOSE
    CLAMP, HOSE
  • 4
    8428-002 NUT, LOCK
    NUT, LOCK
  • 5
    0423-426 WASHER
    WASHER
  • 6
    0423-404 SCREW, CAP
    SCREW, CAP
  • 7
    8408-820 SCREW, CAP
    SCREW, CAP
  • 8
    1502-338 DRIVESHAFT, REAR - ASSEMBLY (INC. 9-13)
    DRIVESHAFT, REAR - ASSEMBLY (INC. 9-13)
  • 9
    1402-689 ...YOKE, FLANGE
    ...YOKE, FLANGE
  • 10
    0402-944 ...JOINT, UNIVERSAL (INC. 11)
    ...JOINT, UNIVERSAL (INC. 11)
  • 11
    0423-395 ......RING, RETAINING
    ......RING, RETAINING
  • 12
    1502-337 ...DRIVESHAFT, REAR
    ...DRIVESHAFT, REAR
  • 13
    1402-567 ...YOKE, SLIP
    ...YOKE, SLIP
  • 14
    2502-085 GEARCASE, REAR
    GEARCASE, REAR
  • 15
    0423-830 BOLT, HFH M10-1.25X125 CL10.9 ZY
    BOLT, HFH M10-1.25X125 CL10.9 ZY
