HYDRAULIC BRAKE ASSEMBLY для Arctic Cat ALTERRA 700 XT EPS WHITE T3S [A2016XCT1PSTW] - 2016 года выпуска

  • №
    Артикул
    Название
  • 1
    1436-422 CALIPER, BRAKE (FRONT RIGHT & REAR RIGHT) (INC. 2-9)
    CALIPER, BRAKE (FRONT RIGHT & REAR RIGHT) (INC. 2-9)
  • 1
    1436-423 CALIPER, BRAKE (FRONT LEFT) (INC. 2-9)
    CALIPER, BRAKE (FRONT LEFT) (INC. 2-9)
  • 2
    1436-160 ...HOUSING, CALIPER - ASSEMBLY (FRONT RIGHT & REAR RIGHT) (INC. 3-6)
    ...HOUSING, CALIPER - ASSEMBLY (FRONT RIGHT & REAR RIGHT) (INC. 3-6)
  • 2
    1436-161 ...HOUSING, CALIPER - ASSEMBLY (FRONT LEFT) (INC. 3-6)
    ...HOUSING, CALIPER - ASSEMBLY (FRONT LEFT) (INC. 3-6)
  • 3
    8408-826 SCREW, CAP
    SCREW, CAP
  • 4
    0502-606 PISTON/SEAL SET (INC. 5)
    PISTON/SEAL SET (INC. 5)
  • 5
    0502-607 ...SEAL SET
    ...SEAL SET
  • 6
    0502-609 VALVE, BLEED
    VALVE, BLEED
  • 7
    0502-608 O-RING, GUIDE - SET
    O-RING, GUIDE - SET
  • 8
    0502-605 BRACKET ASSEMBLY
    BRACKET ASSEMBLY
  • 9
    1436-420 PAD, BRAKE - SET
    PAD, BRAKE - SET
  • 10
    8476-625 SCREW, MACHINE
    SCREW, MACHINE
  • 11
    2402-259 HOSE, BRAKELINE - FRONT
    HOSE, BRAKELINE - FRONT
  • 12
    0403-257 BRACKET, BRAKELINE
    BRACKET, BRAKELINE
  • 13
    1502-594 CLAMP, ROUTING
    CLAMP, ROUTING
  • 14
    0423-946 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 15
    2502-249 LEVER, BRAKE
    LEVER, BRAKE
  • 16
    8408-816 SCREW, CAP
    SCREW, CAP
  • 17
    8050-252 WASHER
    WASHER
  • 18
    1602-213 O-RING
    O-RING
  • 19
    2402-258 HOSE
    HOSE
  • 20
    3313-316 CYLINDER, MASTER BRAKE - ASSEMBLY (INC. 21-28)
    CYLINDER, MASTER BRAKE - ASSEMBLY (INC. 21-28)
  • 21
    0502-566 ...SCREW, MACHINE
    ...SCREW, MACHINE
  • 22
    0502-868 ...COVER, RESERVOIR
    ...COVER, RESERVOIR
  • 23
    0502-568 ...SCREW, MACHINE
    ...SCREW, MACHINE
  • 24
    0502-869 ...CLAMP, HANDLEBAR
    ...CLAMP, HANDLEBAR
  • 25
    0502-704 ...MASTER CYLINDER ASSEMBLY
    ...MASTER CYLINDER ASSEMBLY
  • 26
    1502-904 ...LEVER ASSEMBLY - KIT (INC. 27-28)
    ...LEVER ASSEMBLY - KIT (INC. 27-28)
  • 27
    1502-905 ......LOCK, BRAKE LEVER - KIT
    ......LOCK, BRAKE LEVER - KIT
  • 28
    0502-580 ......LEVER PIN - KIT
    ......LEVER PIN - KIT
  • 29
    8408-625 SCREW, CAP
    SCREW, CAP
  • 30
    2402-302 HOSE, BRAKELINE
    HOSE, BRAKELINE
  • 31
    3313-238 PRESSURE, SWITCH
    PRESSURE, SWITCH
  • 32
    0423-178 WASHER, CRUSH
    WASHER, CRUSH
  • 33
    0423-413 BOLT, BANJO-FITTING
    BOLT, BANJO-FITTING
  • 34
    2402-247 BRAKE ASSEMBLY
    BRAKE ASSEMBLY
  • 35
    0117-868 PIN, COTTER
    PIN, COTTER
  • 36
    8050-217 WASHER
    WASHER
  • 37
    1402-377 PIN, CLEVIS
    PIN, CLEVIS
  • 38
    2402-233 CLIP, BRAKE HOSE
    CLIP, BRAKE HOSE
  • 39
    5639-848 FLUID, BRAKE - 12 OZ
    FLUID, BRAKE - 12 OZ
  • 40
    0123-788 TIE, CABLE - 8 IN.
    TIE, CABLE - 8 IN.
  • 41
    0623-677 TIE, CABLE - PUSH-MOUNT
    TIE, CABLE - PUSH-MOUNT
