WIRING HARNESS ASSEMBLY для Arctic Cat XC 450 4x4 [A2013KCK4CUST] - 2013 года выпуска

  • №
    Артикул
    Название
  • 1
    0486-474 HARNESS, MAIN (INC. 2-6)
    HARNESS, MAIN (INC. 2-6)
  • 2
    0530-008 ...COVER, FUSE BLOCK
    ...COVER, FUSE BLOCK
  • 3
    0430-037 ...HOLDER, FUSE
    ...HOLDER, FUSE
  • 4
    0430-032 ...FUSE - 10 AMP
    ...FUSE - 10 AMP
  • 4
    0430-031 ...FUSE - 15 AMP
    ...FUSE - 15 AMP
  • 4
    3304-212 ...FUSE - 30 AMP
    ...FUSE - 30 AMP
  • 5
    2411-566 ...DECAL, FUSE BLOCK
    ...DECAL, FUSE BLOCK
  • 6
    0430-045 ...RELAY (4-PIN) - 20 AMP
    ...RELAY (4-PIN) - 20 AMP
  • 6
    0430-033 ...RELAY (5-PIN) - 30 AMP
    ...RELAY (5-PIN) - 30 AMP
  • 7
    3306-327 SCREW, CAP
    SCREW, CAP
  • 8
    3306-325 SENSOR, TILT
    SENSOR, TILT
  • 9
    0423-345 CLIP, RETAINING
    CLIP, RETAINING
  • 10
    3306-454 TRAY, ELECTRICAL
    TRAY, ELECTRICAL
  • 11
    3304-586 SCREW, CAP
    SCREW, CAP
  • 12
    0530-098 ECM
    ECM
  • 13
    3304-431 NUT, LOCK
    NUT, LOCK
  • 14
    3304-654 NUT, LOCK
    NUT, LOCK
  • 15
    3306-517 REGULATOR, VOLTAGE
    REGULATOR, VOLTAGE
  • 16
    3305-344 SCREW, CAP
    SCREW, CAP
  • 17
    3306-326 SCREW, CAP
    SCREW, CAP
  • 18
    0824-073 COIL, IGNITION - ASSEMBLY (INC. 19)
    COIL, IGNITION - ASSEMBLY (INC. 19)
  • 19
    0824-056 ...CAP, SPARK PLUG
    ...CAP, SPARK PLUG
  • 20
    3303-289 TIE, CABLE
    TIE, CABLE
