REAR SUSPENSION ASSEMBLY для Arctic Cat 650 H1 TRV (CAT GREEN) [A2009TBS4BUSZ] - 2009 года выпуска
-
№АртикулНазвание
-
10504-548 KNUCKLE, RIGHT REAR - ASSEMBLY (INC. 2-5)KNUCKLE, RIGHT REAR - ASSEMBLY (INC. 2-5)
-
10504-549 KNUCKLE, LEFT REAR - ASSEMBLY (INC. 2-5)KNUCKLE, LEFT REAR - ASSEMBLY (INC. 2-5)
-
21402-809 BEARINGBEARING
-
30423-423 RING, RETAININGRING, RETAINING
-
40403-038 AXLEAXLE
-
50403-032 BUSHINGBUSHING
-
60504-576 A-ARM, REAR-LOWER RIGHT-PLATINUM (INC. 7-8)A-ARM, REAR-LOWER RIGHT-PLATINUM (INC. 7-8)
-
60504-577 A-ARM, REAR-LOWER LEFT-PLATINUM (INC. 7-8)A-ARM, REAR-LOWER LEFT-PLATINUM (INC. 7-8)
-
70403-115 BUSHINGBUSHING
-
80403-114 AXLEAXLE
-
90423-744 NUT, LOCKNUT, LOCK
-
108409-000 SCREW, CAPSCREW, CAP
-
110504-586 A-ARM, REAR-UPPER RIGHT-PLATINUM (INC. 7-8)A-ARM, REAR-UPPER RIGHT-PLATINUM (INC. 7-8)
-
110504-587 A-ARM, REAR-UPPER LEFT-PLATINUM (INC. 7-8)A-ARM, REAR-UPPER LEFT-PLATINUM (INC. 7-8)
-
120441-758 GUARD, BOOT - REAR - RIGHT - CAT GREENGUARD, BOOT - REAR - RIGHT - CAT GREEN
-
120441-759 GUARD, BOOT - REAR - LEFT - CAT GREENGUARD, BOOT - REAR - LEFT - CAT GREEN
-
130423-545 SCREW, BODY-SELF TAP #12 X 3/4 A Z & BSCREW, BODY-SELF TAP #12 X 3/4 A Z & B
-
148409-075 SCREW, CAP-HFH M10X1.25X75 CL10.9 Z & YSCREW, CAP-HFH M10X1.25X75 CL10.9 Z & Y
-
151502-343 HALFSHAFT, 565MM-27T (INC. 16-17)HALFSHAFT, 565MM-27T (INC. 16-17)
-
160423-845 CLIP, RETAININGCLIP, RETAINING
-
170436-276 REPAIR KIT, BOOTREPAIR KIT, BOOT
-
180123-788 TIE, CABLE - 8 IN.TIE, CABLE - 8 IN.
-
191603-889 RETAINER, SPRINGRETAINER, SPRING
-
200504-543 SPRING, SUSPENSION - PLATINUMSPRING, SUSPENSION - PLATINUM
-
210404-057 CAM, SPRING ADJUSTERCAM, SPRING ADJUSTER
-
220404-158 SHOCK ABSORBER (INC. 23-25)SHOCK ABSORBER (INC. 23-25)
-
230403-182 BUSHING, DOUBLE-BONDEDBUSHING, DOUBLE-BONDED
-
240603-955 BUSHINGBUSHING
-
251603-219 SLEEVESLEEVE
-
260423-087 WASHERWASHER
-
278408-820 SCREW, CAP-HFH M8X1.25X20 CL8.8 Z & YSCREW, CAP-HFH M8X1.25X20 CL8.8 Z & Y
-
288409-050 SCREW, CAP-HFH M10X1.25X50 CL10.9 Z & YSCREW, CAP-HFH M10X1.25X50 CL10.9 Z & Y
