TRANSMISSION LEFT-SIDE ASSEMBLY для Arctic Cat 700 DIESEL (RED) [A2008TBT4DUSR] - 2008 года выпуска

  • №
    Артикул
    Название
  • 1
    0832-014 BEARING
    BEARING
  • 2
    0828-010 WASHER, THRUST - SECONDARY TRANSMISSION
    WASHER, THRUST - SECONDARY TRANSMISSION
  • 3
    1402-558 GEAR, DRIVE - NO. 2 (18T)
    GEAR, DRIVE - NO. 2 (18T)
  • 4
    1502-149 COUNTERSHAFT (INC. 5-18)
    COUNTERSHAFT (INC. 5-18)
  • 5
    0831-011 ...RING, RETAINING
    ...RING, RETAINING
  • 6
    0822-014 ...DOG, REVERSE GEAR
    ...DOG, REVERSE GEAR
  • 7
    0822-045 ...INSERT, GEAR
    ...INSERT, GEAR
  • 8
    0828-008 ...WASHER, SECONDARY TRANSMISSION
    ...WASHER, SECONDARY TRANSMISSION
  • 9
    0822-013 ...GEAR, REVERSE DRIVEN
    ...GEAR, REVERSE DRIVEN
  • 10
    0832-011 ...BEARING
    ...BEARING
  • 11
    0822-005 ...BUSHING
    ...BUSHING
  • 12
    0828-015 ...WASHER, LOCK - SECONDARY TRANSMISSION
    ...WASHER, LOCK - SECONDARY TRANSMISSION
  • 13
    0828-014 ...WASHER, SECONDARY TRANSMISSION
    ...WASHER, SECONDARY TRANSMISSION
  • 14
    0822-004 ...GEAR, DRIVEN - LOW (40T)
    ...GEAR, DRIVEN - LOW (40T)
  • 15
    0822-046 ...SHIM, DRIVE GEAR SPACER
    ...SHIM, DRIVE GEAR SPACER
  • 16
    0822-003 ...COUNTERSHAFT
    ...COUNTERSHAFT
  • 17
    0822-007 ...DOG, SLIDING DRIVEN GEAR - HIGH/LOW
    ...DOG, SLIDING DRIVEN GEAR - HIGH/LOW
  • 18
    0822-006 ...GEAR, DRIVEN - HIGH (30T)
    ...GEAR, DRIVEN - HIGH (30T)
  • 19
    0828-011 WASHER
    WASHER
  • 20
    0818-072 FORK, SHIFT
    FORK, SHIFT
  • 21
    0818-006 SHAFT, SHIFT FORK
    SHAFT, SHIFT FORK
  • 22
    0822-052 SEAL, COUNTERSHAFT - RIGHT
    SEAL, COUNTERSHAFT - RIGHT
  • 23
    0831-040 RING, EXTERNAL RETAINING
    RING, EXTERNAL RETAINING
  • 24
    0822-050 TRIGGER, SPEEDOMETER SENSOR
    TRIGGER, SPEEDOMETER SENSOR
  • 25
    0828-069 WASHER, THRUST
    WASHER, THRUST
  • 26
    0831-039 RING, EXTERNAL RETAINING
    RING, EXTERNAL RETAINING
  • 27
    0830-129 GASKET, ODOMETER DRIVE
    GASKET, ODOMETER DRIVE
  • 28
    0829-023 PIN, SOLID DOWEL
    PIN, SOLID DOWEL
  • 29
    0822-049 HOUSING, SPEEDOMETER SENSOR
    HOUSING, SPEEDOMETER SENSOR
  • 30
    0830-107 SEAL, FASTENER
    SEAL, FASTENER
  • 31
    8468-645 SCREW, MACHINE
    SCREW, MACHINE
  • 32
    0824-042 SENSOR, SPEEDOMETER
    SENSOR, SPEEDOMETER
  • 33
    8468-620 SCREW, MACHINE
    SCREW, MACHINE
  • 34
    0828-038 WASHER
    WASHER
  • 35
    0818-002 STOPPER, SWING ARM - CAM ASSEMBLY
    STOPPER, SWING ARM - CAM ASSEMBLY
  • 36
    0818-004 SUPPORT, CAM STOPPER
    SUPPORT, CAM STOPPER
  • 37
    0818-028 SPRING, TORSION - CAM ARM
    SPRING, TORSION - CAM ARM
  • 38
    0828-035 WASHER
    WASHER
  • 39
    8424-602 NUT, HEX FLANGE
    NUT, HEX FLANGE
  • 40
    1402-556 STOP, SPRING - SELECTOR
    STOP, SPRING - SELECTOR
  • 41
    0828-036 WASHER
    WASHER
  • 42
    0831-010 RING, RETAINING
    RING, RETAINING
  • 43
    0818-007 SHAFT, SUB - GEAR SHIFT
    SHAFT, SUB - GEAR SHIFT
  • 44
    1402-557 GASKET, COVER - SELECTOR
    GASKET, COVER - SELECTOR
  • 45
    1502-009 COVER, SELECTOR - GEARCASE
    COVER, SELECTOR - GEARCASE
  • 46
    8405-620 SCREW, CAP
    SCREW, CAP
  • 47
    0830-044 SEAL, SUB - GEAR SHIFT
    SEAL, SUB - GEAR SHIFT
  • 48
    0818-014 ARM, SELECTOR
    ARM, SELECTOR
  • 49
    0818-005 PLATE, GEAR SHIFT CAM
    PLATE, GEAR SHIFT CAM
  • 50
    0826-006 SCREW, CAP
    SCREW, CAP
  • 51
    0812-006 PLUG, DRAIN - MAGNETIC
    PLUG, DRAIN - MAGNETIC
  • 52
    0830-017 GASKET, COMPRESSION
    GASKET, COMPRESSION
  • 53
    1402-102 FITTING, 90?
    FITTING, 90?
  • 54
    0402-333 PLUG, FILL
    PLUG, FILL
  • 55
    0830-010 O-RING
    O-RING
  • 56
    0819-063 YOKE, PROPELLER SHAFT
    YOKE, PROPELLER SHAFT
  • 57
    1402-463 JOINT, UNIVERSAL - SET (INC. 58)
    JOINT, UNIVERSAL - SET (INC. 58)
  • 58
    0423-450 ...RING, RETAINING - UNIVERSAL JOINT
    ...RING, RETAINING - UNIVERSAL JOINT
  • 59
    0827-013 NUT, HEX
    NUT, HEX
  • 60
    0828-020 WASHER
    WASHER
  • 61
    0819-061 YOKE, DRIVE OUTPUT - FRONT ASSEMBLY
    YOKE, DRIVE OUTPUT - FRONT ASSEMBLY
  • 62
    0830-043 SEAL, OIL - DRIVEN SHAFT
    SEAL, OIL - DRIVEN SHAFT
  • 63
    0832-017 BEARING, DRIVEN SHAFT
    BEARING, DRIVEN SHAFT
  • 64
    0828-026 SHIM, 25.00 X 34.00 X 1.00
    SHIM, 25.00 X 34.00 X 1.00
  • 65
    1402-554 SHAFT, OUTPUT - SECONDARY
    SHAFT, OUTPUT - SECONDARY
  • 66
    0819-002 GEAR, SECONDARY DRIVEN
    GEAR, SECONDARY DRIVEN
  • 67
    1402-555 SLEEVE, BEARING - OUTPUT SHAFT
    SLEEVE, BEARING - OUTPUT SHAFT
  • 68
    0832-016 BEARING, DRIVEN GEAR
    BEARING, DRIVEN GEAR
  • 69
    0819-011 RING, DRIVEN BEARING
    RING, DRIVEN BEARING
  • 70
    0819-005 FLANGE, OUTPUT JOINT - ASSEMBLY
    FLANGE, OUTPUT JOINT - ASSEMBLY
  • 71
    0470-689 LEVEL STICK, LUBRICANT
    LEVEL STICK, LUBRICANT
  • 72
    2506-388 TUBE, LEVEL STICK (BLACK)
    TUBE, LEVEL STICK (BLACK)
  • 73
    0423-465 GROMMET
    GROMMET
  • 74
    2506-445 BRACKET, LEVEL STICK TUBE
    BRACKET, LEVEL STICK TUBE
  • 75
    0423-715 O-RING
    O-RING
  • 76
    0423-396 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
