WATER PUMP ASSY для Yamaha V-MAX 700 DELUXE - 2000 года выпуска`
-
№АртикулНазвание
-
18CH-12459-01-00 GEAR, IMPELLER SHAFTGEAR, IMPELLER SHAFT
-
293306-00106-00 BEARINGBEARING
-
393306-00004-00 BEARINGBEARING
-
411H-12438-00-00 SEAL, MECHANICALSEAL, MECHANICAL
-
593102-12461-00 OIL SEAL, SD-TYPEOIL SEAL, SD-TYPE
-
699009-28500-00 CIRCLIPCIRCLIP
-
78CH-12451-02-00 IMPELLER, WATER PUMPIMPELLER, WATER PUMP
-
895827-06012-00 BOLT, FLANGEBOLT, FLANGE
-
990210-06018-00 WASHER, SEALWASHER, SEAL
-
108CH-12422-10-00 COVER, HOUSINGCOVER, HOUSING
-
118CH-12469-00-00 JOINT 1JOINT 1
-
128CH-12439-00-00 O-RINGO-RING
-
1395817-06020-00 BOLT, FLANGEBOLT, FLANGE
-
1490430-06166-00 GASKETGASKET
