SEAT для Yamaha XL 800 - 2000 года выпуска
-
№АртикулНазвание
-
1F0D-U371A-20-00 DOUBLE SEAT ASSY (YMUS)DOUBLE SEAT ASSY (YMUS)
-
2F0D-U371B-20-00 ...COVER, SEAT 1 (YMUS)...COVER, SEAT 1 (YMUS)
-
3F0D-U266C-00-00 PACKING 4 (YMUS)PACKING 4 (YMUS)
-
4F0D-63850-01-00 SEAT LOCK ASSYSEAT LOCK ASSY
-
590119-069UP-00 BOLT, WITH WASHER (YMUS)BOLT, WITH WASHER (YMUS)
-
6F0D-U372A-20-00 SINGLE SEAT ASSY (YMUS)SINGLE SEAT ASSY (YMUS)
-
7F0D-U372B-20-00 ...COVER, SEAT (YMUS)...COVER, SEAT (YMUS)
-
8F0D-63850-01-00 SEAT LOCK ASSYSEAT LOCK ASSY
-
990119-069UP-00 BOLT, WITH WASHER (YMUS)BOLT, WITH WASHER (YMUS)
-
10F0D-6378C-00-00 STAY, SEAT 1STAY, SEAT 1
-
119299R-06200-00 WASHER (YMUS)WASHER (YMUS)
-
129572R-06300-00 NUT, FLANGE (YMUS)NUT, FLANGE (YMUS)
-
13F0D-6378D-01-00 STAY,SEAT 2STAY,SEAT 2
-
1497080-10025-00 BOLTBOLT
-
159299R-10200-00 WASHER (YMUS)WASHER (YMUS)
-
169572R-10300-00 NUT, FLANGE (YMUS)NUT, FLANGE (YMUS)
-
17F0D-U271B-00-00 GRIP, HAND (YMUS)GRIP, HAND (YMUS)
-
1890119-06820-00 BOLT, WITH WASHER (YMUS)BOLT, WITH WASHER (YMUS)
-
199299R-06200-00 WASHER (YMUS)WASHER (YMUS)
-
209572R-06300-00 NUT, FLANGE (YMUS)NUT, FLANGE (YMUS)
-
21F0D-U474A-00-00 UNDER LOCKER ASSY (YMUS)UNDER LOCKER ASSY (YMUS)
-
22F0D-U266D-00-00 ...PACKING 5 (YMUS)...PACKING 5 (YMUS)
-
23GP7-61628-00-00 STERN EYESTERN EYE
-
249572R-08300-00 NUT, FLANGE (YMUS)NUT, FLANGE (YMUS)
-
25GP7-U4953-00-00 PLATE A (YMUS)PLATE A (YMUS)
-
26GH1-U3774-00-00 PIN (YMUS)PIN (YMUS)
-
279299R-10200-00 WASHER (YMUS)WASHER (YMUS)
-
289572R-10300-00 NUT, FLANGE (YMUS)NUT, FLANGE (YMUS)
-
29F0D-6376D-00-00 PLATE, DAMPERPLATE, DAMPER
