PROPULSION SYSTEM - EXTERNAL для Yamaha GP 800 - 2000 года выпуска`
-
№АртикулНазвание
-
190480-06M46-00 GROMMETGROMMET
-
266E-51381-01-00 COVERCOVER
-
390480-06M46-00 GROMMETGROMMET
-
465V-51311-01-94 DUCT, INTAKEDUCT, INTAKE
-
593102-17M49-00 OIL SEALOIL SEAL
-
693102-17M50-00 OIL SEALOIL SEAL
-
765V-45318-00-00 BUSHING, DRIVE SHAFTBUSHING, DRIVE SHAFT
-
865U-R1348-01-00 SPACER (YMUS)SPACER (YMUS)
-
990119-069UD-00 BOLT, WITH WASHER (YMUS)BOLT, WITH WASHER (YMUS)
-
106R8-51367-01-00 FELT, PACKINGFELT, PACKING
-
116R8-51312-03-94 HOUSING, IMPELLERHOUSING, IMPELLER
-
1293606-12019-00 PIN, DOWELPIN, DOWEL
-
1366E-51315-00-94 DUCT, IMPELLERDUCT, IMPELLER
-
1466E-46882-00-00 FILTERFILTER
-
1566E-45214-00-94 COVER, WATER INLETCOVER, WATER INLET
-
1666E-42414-00-00 O-RINGO-RING
-
1790119-069UW-00 BOLT, WITH WASHER (YMUS)BOLT, WITH WASHER (YMUS)
-
1866E-4383A-00-00 HOSEHOSE
-
1990601-118UF-00 BAND, HOSE 18 (YMUS)BAND, HOSE 18 (YMUS)
-
2093606-12019-00 PIN, DOWELPIN, DOWEL
-
2193306-205U0-00 BEARINGBEARING
-
2293102-25M34-00 OIL SEALOIL SEAL
-
2393101-25M50-00 OIL SEALOIL SEAL
-
2465V-45538-00-00 SPACER 1SPACER 1
-
2593306-304U1-00 BEARINGBEARING
-
2666E-45511-10-00 SHAFT, DRIVESHAFT, DRIVE
-
2792990-16600-00 WASHERWASHER
-
2895317-16700-00 NUTNUT
-
2965A-R1326-00-00 CAP (YMUS)CAP (YMUS)
-
3093210-46M16-00 O-RINGO-RING
-
3190119-069UB-00 BOLT, WITH WASHER (YMUS)BOLT, WITH WASHER (YMUS)
-
3266E-51321-B0-00 IMPELLERIMPELLER
-
3362T-51348-00-00 SPACERSPACER
-
3465V-51318-00-94 NOZZLENOZZLE
-
356K8-51129-00-00 ...NIPPLE...NIPPLE
-
3662T-51129-00-00 ...NIPPLE...NIPPLE
-
3761X-51673-00-00 PIPE 1PIPE 1
-
3890601-118UF-00 BAND, HOSE 18 (YMUS)BAND, HOSE 18 (YMUS)
-
3993606-12019-00 PIN, DOWELPIN, DOWEL
-
4090119-06829-00 BOLT, WITH WASHER (YMUS)BOLT, WITH WASHER (YMUS)
-
4165V-51313-00-00 NOZZLE, DEFLECTORNOZZLE, DEFLECTOR
-
4290119-089UE-00 BOLT, WITH WASHER (YMUS)BOLT, WITH WASHER (YMUS)
-
4390387-08M08-00 COLLARCOLLAR
-
4464Y-51190-00-94 RING,TRIMRING,TRIM
-
45GH3-U146E-00-00 STUD, JOINT BALL (YMUS)STUD, JOINT BALL (YMUS)
-
4690201-068M4-00 WASHER, PLATE (YMUS)WASHER, PLATE (YMUS)
-
4795380-06700-00 NUTNUT
-
4890119-089UE-00 BOLT, WITH WASHER (YMUS)BOLT, WITH WASHER (YMUS)
-
4990387-08M06-00 COLLARCOLLAR
