SIDE COVERS для Yamaha GP 800 - 2000 года выпуска`
-
№АртикулНазвание
-
1GP7-U516A-00-00 ENGINE HATCH COMP. (YMUS)ENGINE HATCH COMP. (YMUS)
-
290119-089U5-00 BOLT, WITH WASHER (YMUS)BOLT, WITH WASHER (YMUS)
-
390109-08913-00 BOLTBOLT
-
490201-099U1-00 WASHER, PLATE (YMUS)WASHER, PLATE (YMUS)
-
592990-08100-00 WASHER, SPRINGWASHER, SPRING
-
6GP7-U266F-00-00 PACKING 7 (YMUS)PACKING 7 (YMUS)
-
7GU0-U516N-10-P0 COVER, ENGINE HATCHCOVER, ENGINE HATCH
-
8GP7-6515G-01-00 DAMPER 3DAMPER 3
-
99299R-06200-00 WASHER (YMUS)WASHER (YMUS)
-
109572R-06300-00 NUT, FLANGE (YMUS)NUT, FLANGE (YMUS)
-
11GP7-U5114-00-00 RUBBER, WATER PROOF (YMUS)RUBBER, WATER PROOF (YMUS)
-
12GP7-U517M-01-00 PAD,HATCH 1 (YMUS)PAD,HATCH 1 (YMUS)
-
1390160-05804-00 SCREW, ROUND TAPPINGSCREW, ROUND TAPPING
-
1490119-06959-00 BOLT, WITH WASHERBOLT, WITH WASHER
-
1590480-13907-00 GROMMETGROMMET
-
1690387-06920-00 COLLARCOLLAR
-
17GP7-U517H-40-P0 LID HATCH (YMUS)LID HATCH (YMUS)
-
1898580-05520-00 SCREW, PAN HEADSCREW, PAN HEAD
-
19GP7-6287A-00-00 LOCK ASSYLOCK ASSY
-
20GP7-62848-00-00 ...PLATE, HOOK...PLATE, HOOK
-
21EW2-62846-00-00 ...PLATE, HATCH LOCK...PLATE, HATCH LOCK
-
22GP7-6284J-00-00 ...HOOK, LOCK...HOOK, LOCK
-
23GP7-62873-00-00 ...NUT, SPECIAL...NUT, SPECIAL
-
2498580-05510-00 SCREW, PAN HEADSCREW, PAN HEAD
-
25GP7-U5148-00-00 PLATE, HOOD (YMUS)PLATE, HOOD (YMUS)
-
26GP7-6517G-01-00 HINGE, HATCHHINGE, HATCH
-
2798780-05020-00 SCREW, FLAT HEADSCREW, FLAT HEAD
-
289572R-05300-00 NUT, FLANGE (YMUS)NUT, FLANGE (YMUS)
-
29GP7-U517S-00-00 PLATE, HATCH 2 (YMUS)PLATE, HATCH 2 (YMUS)
-
30GP7-U516P-00-00 BOX GLOVE (YMUS)BOX GLOVE (YMUS)
-
3190605-502U2-00 PLUG (YMUS)PLUG (YMUS)
-
3290267-489UK-00 RIVET, BLIND (YMUS)RIVET, BLIND (YMUS)
-
33GP7-U519D-02-00 PACKING CASE (YMUS)PACKING CASE (YMUS)
-
3490179-08967-00 NUTNUT
-
35GP7-U377B-10-00 COVER,SIDE 1 (YMUS)COVER,SIDE 1 (YMUS)
-
36GP7-U377C-10-00 COVER,SIDE 2 (YMUS)COVER,SIDE 2 (YMUS)
-
3790267-489UN-00 RIVET, BLIND (YMUS)RIVET, BLIND (YMUS)
-
3890338-09828-00 PLUG (YMUS)PLUG (YMUS)
