AIR CLEANER W/ INTAKE для Yamaha YZF-R1 - 2010 года выпуска`
-
№АртикулНазвание
-
114B-13750-00-00 THROTTLE BODY ASSY (EXCEPT CALIF.)THROTTLE BODY ASSY (EXCEPT CALIF.)
-
114B-13750-10-00 THROTTLE BODY ASSY (CALIF. ONLY)THROTTLE BODY ASSY (CALIF. ONLY)
-
214B-13761-00-00 INJECTORINJECTOR
-
35PS-14147-00-00 O-RINGO-RING
-
48FP-13556-00-00 GASKET, MANIFOLDGASKET, MANIFOLD
-
55PW-14396-00-00 PIPEPIPE
-
68CC-14216-10-00 SCREWSCREW
-
713S-85885-00-00 THROTTLE SENSOR ASSYTHROTTLE SENSOR ASSY
-
82C0-82380-00-00 SENSOR, PRESSURESENSOR, PRESSURE
-
92C0-14216-00-00 SCREWSCREW
-
105FL-14216-00-00 SCREWSCREW
-
1113S-85884-00-00 ACCELERATOR SENSOR ASSYACCELERATOR SENSOR ASSY
-
12895-14169-00-00 CAPCAP
-
138A7-14139-00-00 CLIP, PIPECLIP, PIPE
-
142C0-14105-00-00 PILOT SCREW SETPILOT SCREW SET
-
1514B-82386-00-00 EXTENSION, WIRE HARNESSEXTENSION, WIRE HARNESS
-
164KM-14137-00-00 CLIPCLIP
-
175FL-14348-10-00 PIPE 1PIPE 1
-
185JW-24311-00-00 PIPE, FUEL 1PIPE, FUEL 1
-
1968V-24376-00-00 PIPE, JOINT 1PIPE, JOINT 1
-
205JW-14348-00-00 PIPE 1PIPE 1
-
215PW-14349-00-00 PIPEPIPE
-
2290467-09006-00 CLIP, SCISSOR (CALIF. ONLY)CLIP, SCISSOR (CALIF. ONLY)
-
2390413-06031-00 WAY 3 CALIF. ONLY)WAY 3 CALIF. ONLY)
-
2414B-13971-00-00 PIPE, FUEL 1PIPE, FUEL 1
-
2590464-16005-00 CLAMPCLAMP
