SHIFT SHAFT для Yamaha FZ6 - 2008 года выпуска`
-
№АртикулНазвание
-
190506-14003-00 SPRING, TENSIONSPRING, TENSION
-
2132-16346-00-00 HOOK, SPRINGHOOK, SPRING
-
35VX-18140-00-00 STOPPER LEVER ASSYSTOPPER LEVER ASSY
-
490387-127V3-00 COLLARCOLLAR
-
599009-17400-00 CIRCLIPCIRCLIP
-
690201-177G4-00 WASHER, PLATEWASHER, PLATE
-
790201-154E8-00 WASHER, PLATE (T=1.0)WASHER, PLATE (T=1.0)
-
81D7-18127-00-00 STOPPER, SCREWSTOPPER, SCREW
-
95VX-18101-11-00 SHIFT SHAFT ASSYSHIFT SHAFT ASSY
-
1090508-295B2-00 ...SPRING, TORSION...SPRING, TORSION
-
115VX-18112-01-00 ARM, SHIFTARM, SHIFT
-
1295824-06020-00 BOLT, FLANGEBOLT, FLANGE
-
135VX-18110-00-00 SHIFT PEDAL ASSYSHIFT PEDAL ASSY
-
145EB-18113-00-00 ...COVER, SHIFT PEDAL...COVER, SHIFT PEDAL
-
1590201-12013-00 WASHER, PLATEWASHER, PLATE
-
1690206-12074-00 WASHER, WAVEWASHER, WAVE
-
174BP-27434-01-00 BOLTBOLT
-
1890201-08784-00 WASHER, PLATEWASHER, PLATE
-
195VX-18115-02-00 ROD, SHIFTROD, SHIFT
-
2090170-06228-00 NUT (COUNTER CLOCKWISE)NUT (COUNTER CLOCKWISE)
-
2195304-06700-00 NUTNUT
-
225VX-27442-10-00 BRACKET 2BRACKET 2
-
235VX-27424-00-00 DAMPER, FOOTREST 2DAMPER, FOOTREST 2
-
245VX-27114-00-00 STOPPER, MAIN STANDSTOPPER, MAIN STAND
-
255VX-18116-00-00 JOINT, ROD 1JOINT, ROD 1
-
265VX-18154-00-00 COVER, DUSTCOVER, DUST
-
274S8-27445-00-00 PLATE 1PLATE 1
-
2892014-05012-00 BOLT, BUTTON HEADBOLT, BUTTON HEAD
-
2995607-05100-00 NUT, UNUT, U
-
3092990-05200-00 WASHER, PLAINWASHER, PLAIN
-
314S8-27415-00-00 PLATE, FOOTRESTPLATE, FOOTREST
-
3290111-06019-00 BOLT, HEX. SOCKET BUTTONBOLT, HEX. SOCKET BUTTON
-
3390387-06372-00 COLLARCOLLAR
-
3493317-11295-00 BEARINGBEARING
-
3593102-12106-00 OIL SEAL (SD 12-22-5 HS)OIL SEAL (SD 12-22-5 HS)
