STARTER - RECOIL для Yamaha BREEZE YFA1S - 2004 года выпуска`
-
№АртикулНазвание
-
13FA-15710-00-00 STARTER ASSY (OPT)STARTER ASSY (OPT)
-
23FA-15711-00-00 ...CASE, STARTER...CASE, STARTER
-
33FA-15714-00-00 ...DRUM, SHEAVE...DRUM, SHEAVE
-
436R-15741-01-00 ...PAWL, DRIVE...PAWL, DRIVE
-
536R-15713-00-00 ...SPRING, STARTER...SPRING, STARTER
-
636R-15715-00-00 ...SPRING, FRICTION...SPRING, FRICTION
-
736R-15767-00-00 ...SPRING...SPRING
-
836R-15716-00-00 ...PLATE, DRIVE...PLATE, DRIVE
-
997002-06012-00 ...BOLT...BOLT
-
103FA-15751-00-00 ...WIRE, STARTER...WIRE, STARTER
-
113FA-15755-00-00 ...HANDLE, STARTER...HANDLE, STARTER
-
123FA-15726-00-00 ...WASHER, FLAT...WASHER, FLAT
-
133FA-15779-00-00 ...COVER...COVER
-
143FA-15723-01-00 PULLEY, STARTER (OPT)PULLEY, STARTER (OPT)
-
1598507-06012-00 SCREW, PAN HEAD (OPT)SCREW, PAN HEAD (OPT)
-
163FA-15699-10-00 GASKET (OPT)GASKET (OPT)
-
1793102-28476-00 OIL SEAL (OPT)OIL SEAL (OPT)
