WHEEL - FRONT W/ AXLE ASSY для Yamaha TIMBERWOLF 4WD YFB250FWM (4KDL) - 2000 года выпуска
-
№АртикулНазвание
-
14KD-25180-00-35 WHEEL COMP. (SL)WHEEL COMP. (SL)
-
294108-1002G-00 TIRE (AT23X8-10 KT401) (DUNLOP)TIRE (AT23X8-10 KT401) (DUNLOP)
-
393900-00022-00 VALVE, RIM (TAIHEIYO)VALVE, RIM (TAIHEIYO)
-
490179-10540-00 NUTNUT
-
54KD-2510F-01-00 BALL JOINT SETBALL JOINT SET
-
63HN-2510G-00-00 BOOT SET (BALL JOINT)BOOT SET (BALL JOINT)
-
73HN-2510H-00-00 BOOT SET (DOUBLE OFFSET JOINT)BOOT SET (DOUBLE OFFSET JOINT)
-
83HN-2510J-00-00 DOUBLE OFF SET JOINTDOUBLE OFF SET JOINT
-
92HR-2511G-00-00 BOOT BAND (BALL JOINT)BOOT BAND (BALL JOINT)
-
103HN-2511H-00-00 BOOT BAND (DOUBLE OFFSET JOINT)BOOT BAND (DOUBLE OFFSET JOINT)
-
112HR-2512G-00-00 BOOT BAND (SMALL)BOOT BAND (SMALL)
-
122HR-2512H-00-00 CIRCLIPCIRCLIP
-
132HR-2512J-00-00 SNAP RINGSNAP RING
-
1493450-22119-00 CIRCLIPCIRCLIP
-
154KD-23501-01-00 STEERING, KNUCKLE ASSY (LEFT)STEERING, KNUCKLE ASSY (LEFT)
-
1693306-00615-00 ...BEARING...BEARING
-
1793106-38046-00 ...OIL SEAL...OIL SEAL
-
1893106-38047-00 ...OIL SEAL...OIL SEAL
-
1990560-30325-00 ...SPACER...SPACER
-
2090387-281V8-00 COLLARCOLLAR
-
2193210-26606-00 O-RINGO-RING
-
223HN-25111-10-00 HUB, FRONTHUB, FRONT
-
2390114-10012-00 ...BOLT, SERRATION...BOLT, SERRATION
-
2493210-12131-00 ...O-RING...O-RING
-
2590201-162L6-00 WASHER, PLATEWASHER, PLATE
-
265GT-2512A-00-00 CAP, WHEELCAP, WHEEL
-
2790171-16048-00 NUT, CASTLENUT, CASTLE
-
2891401-30030-00 PIN, COTTERPIN, COTTER
-
294KD-25180-00-35 WHEEL COMP. (SL)WHEEL COMP. (SL)
-
3094108-1002G-00 TIRE (AT23X8-10 KT401) (DUNLOP)TIRE (AT23X8-10 KT401) (DUNLOP)
-
3193900-00022-00 VALVE, RIM (TAIHEIYO)VALVE, RIM (TAIHEIYO)
-
3290179-10540-00 NUTNUT
-
334KD-2510F-01-00 BALL JOINT SETBALL JOINT SET
-
343HN-2510G-00-00 BOOT SET (BALL JOINT)BOOT SET (BALL JOINT)
-
353HN-2510H-00-00 BOOT SET (DOUBLE OFFSET JOINT)BOOT SET (DOUBLE OFFSET JOINT)
-
363HN-2510J-00-00 DOUBLE OFF SET JOINTDOUBLE OFF SET JOINT
-
372HR-2511G-00-00 BOOT BAND (BALL JOINT)BOOT BAND (BALL JOINT)
-
383HN-2511H-00-00 BOOT BAND (DOUBLE OFFSET JOINT)BOOT BAND (DOUBLE OFFSET JOINT)
-
392HR-2512G-00-00 BOOT BAND (SMALL)BOOT BAND (SMALL)
-
402HR-2512H-00-00 CIRCLIPCIRCLIP
-
412HR-2512J-00-00 SNAP RINGSNAP RING
-
4293450-22119-00 CIRCLIPCIRCLIP
-
434KD-23502-01-00 STEERING, KNUCKLE ASSY (RIGHT)STEERING, KNUCKLE ASSY (RIGHT)
-
4493306-00615-00 ...BEARING...BEARING
-
4593106-38046-00 ...OIL SEAL...OIL SEAL
-
4693106-38047-00 ...OIL SEAL...OIL SEAL
-
4790560-30325-00 ...SPACER...SPACER
-
4890387-281V8-00 COLLARCOLLAR
-
4993210-26606-00 O-RINGO-RING
-
503HN-25111-10-00 HUB, FRONTHUB, FRONT
-
5190114-10012-00 ...BOLT, SERRATION...BOLT, SERRATION
-
5293210-12131-00 ...O-RING...O-RING
-
5390201-162L6-00 WASHER, PLATEWASHER, PLATE
-
545GT-2512A-00-00 CAP, WHEELCAP, WHEEL
-
5590171-16048-00 NUT, CASTLENUT, CASTLE
-
5691401-30030-00 PIN, COTTERPIN, COTTER
-
574KD-2637G-00-00 HOLDER, WIREHOLDER, WIRE
-
584KD-2637H-00-00 HOLDER, WIRE 2HOLDER, WIRE 2
-
5995827-06012-00 BOLT, FLANGEBOLT, FLANGE
