BRACKET REVERSE LOCK для Tohatsu M8B - 2016 года выпуска`
-
№АртикулНазвание
-
13V1Q62112-1 CLAMP BRACKET (R)
Starboard SideCLAMP BRACKET (R)
Starboard Side -
23V1Q62113-1 CLAMP BRACKET (L)
Port SideCLAMP BRACKET (L)
Port Side -
3309-62115-2 BOLT 8-122"
Bracket BoltBOLT 8-122"
Bracket Bolt -
4930403-0800 NYLON NUT 8-P1.25"NYLON NUT 8-P1.25"
-
59401E3-0800 WASHER"WASHER"
-
6307-62116-1 WASHER 8.5-28-1"WASHER 8.5-28-1"
-
73B2-62118-0 DISTANCE PLATE"DISTANCE PLATE"
-
89216E3-0612 SCREW"SCREW"
-
9369-62146-1 STERN BRACKET SPRING"STERN BRACKET SPRING"
-
10921703-0406 SCREW"SCREW"
-
11369-62147-0 WASHER 4.3-16-1.5"WASHER 4.3-16-1.5"
-
12350-62121-2 THRUST ROD"THRUST ROD"
-
13369-62122-2 THRUST ROD SPRING"THRUST ROD SPRING"
-
143B2Q62310-0 SWIVEL BRACKET"SWIVEL BRACKET"
-
15344-67177-1 GREASE FITTING"GREASE FITTING"
-
16345-62441-0 FRICTION PIECE"FRICTION PIECE"
-
17346-62421-1 FRICTION SPRING"FRICTION SPRING"
-
189101E3-0830 BOLT"BOLT"
-
193B2-66322-1 REVERSE LOCK"REVERSE LOCK"
-
203B2-66321-1 REVERSE LOCK ROD"REVERSE LOCK ROD"
-
21945303-0500 E-RING d=5"E-RING d=5"
-
223B2-66315-0 REVERSE LOCK SPRING"REVERSE LOCK SPRING"
-
233B2-66305-0 REVERSE LOCK LINK"REVERSE LOCK LINK"
-
24345-05224-0 ROD SNAP 5-2.5"ROD SNAP 5-2.5"
-
253B2-66302-0 REVERSE LOCK LINK JOINT"REVERSE LOCK LINK JOINT"
-
26951503-0214 SPLIT PIN"SPLIT PIN"
-
273B2Q62010-0 STEERING SHAFT ASSY"STEERING SHAFT ASSY"
-
283B2-62422-0 THRUST PLATE (UPPER) 22-44-2"THRUST PLATE (UPPER) 22-44-2"
-
293B2-62415-0 O-RING 4.25-19.5"O-RING 4.25-19.5"
-
303B2-62417-0 BUSHING"BUSHING"
-
313B2-61301-0 RUBBER MOUNT (UPPER)RUBBER MOUNT (UPPER)
-
323B2-61337-0 DAMPER (UPPER)DAMPER (UPPER)
-
333B2-61336-0 DAMPER (LOWER)DAMPER (LOWER)
-
343B2-61302-0 RUBBER MOUNT (LOWER)RUBBER MOUNT (LOWER)
-
353K9Q61401-0 MOUNT BRACKET (R)
Starboard SideMOUNT BRACKET (R)
Starboard Side -
363K9Q61402-0 MOUNT BRACKET (L)
Port SideMOUNT BRACKET (L)
Port Side -
379101E3-5640 BOLT"BOLT"
-
383A3-62396-1 GROUND L=110"
Drive Shaft Housing -Mount BracketGROUND L=110"
Drive Shaft Housing -Mount Bracket -
39910103-5612 BOLT"BOLT"
-
403A3-62396-1 GROUND L=110"
Drive Shaft Housing -Mount BracketGROUND L=110"
Drive Shaft Housing -Mount Bracket -
413V1-62431-1 TILT STOPPER ASSY"TILT STOPPER ASSY"
-
423AS-62433-0 * TILT STOPPER GRIP"* TILT STOPPER GRIP"
-
43393-62437-1 BUSHING"BUSHING"
-
44369-62439-1 SETTING PLATE"SETTING PLATE"
-
459101E3-5612 BOLT"BOLT"
-
463V1Q62105-0 CLAMP SCREW KIT"CLAMP SCREW KIT"
-
473V1Q62108-0 * CLAMP SCREW ASSY"* CLAMP SCREW ASSY"
-
483V1-62106-0 ** CLAMP SCREW"** CLAMP SCREW"
-
49332Q62102-1 ** CLAMP SCREW HANDLE"** CLAMP SCREW HANDLE"
-
503C8-62104-2 ** RIVET 3-22"** RIVET 3-22"
-
51332-62101-1 * CLAMP SCREW PAD"* CLAMP SCREW PAD"
-
523C8-62107-0 * SHOULDER BOLT"* SHOULDER BOLT"
