OPTIONAL PARTS (ACCESSORIES) для Tohatsu M8B - 2016 года выпуска
-
№АртикулНазвание
-
1312-72201-0 SAFETY ROPE ?4-1000SAFETY ROPE ?4-1000
-
2369-72100-0 TOOL KITTOOL KIT
-
3346-76160-2 RECTIFIER KIT
for MFRECTIFIER KIT
for MF -
43B2-06128-0 ALTERNATOR KIT
for MFALTERNATOR KIT
for MF -
5921521-6625 * SCREW* SCREW
-
6369-76167-0 EXTENSION CORD (LIGHT) L=2000
for MFEXTENSION CORD (LIGHT) L=2000
for MF -
73B7-72530-2 TACHOMETER ASSYTACHOMETER ASSY
-
83B7-72659-0 * METER BULB 12V-1.8W* METER BULB 12V-1.8W
-
93B7-72656-0 * METER DAMPER* METER DAMPER
-
103B7-72661-0 * FITTING PLATE* FITTING PLATE
-
11930103-0500 * NUT* NUT
-
12941303-0500 * SPRING WASHER* SPRING WASHER
-
13361-72539-0 TACHOMETER LEAD WIRE L=6000TACHOMETER LEAD WIRE L=6000
-
14345-67169-0 GROMMET 40-13-3GROMMET 40-13-3
-
15361-72543-0 SEPARATE CORD
YellowSEPARATE CORD
Yellow -
15361-72542-0 SEPARATE CORD
WhiteSEPARATE CORD
White -
163B2B05180-0 VERTICAL STARTER KITVERTICAL STARTER KIT
-
173B2B05911-0 * VERTICAL STARTER GUIDE* VERTICAL STARTER GUIDE
-
189101F4-0654 * BOLT* BOLT
-
19940103-0600 * WASHER* WASHER
-
20930103-0600 * NUT* NUT
-
213B2-05912-0 * SEAL* SEAL
-
23336-60007-0 FLUSHING PLUGFLUSHING PLUG
