PISTON CRANK SHAFT для Tohatsu M6B - 2016 года выпуска`
-
№АртикулНазвание
-
13B2-00069-0 CRANKSHAFT SUB-ASSYCRANKSHAFT SUB-ASSY
-
23B2-00040-0 * CONNECTING ROD* CONNECTING ROD
-
33B2-00043-0 ROLLER BEARING 17-23-14
Big EndROLLER BEARING 17-23-14
Big End -
43B2-00031-0 * CRANKSHAFT A* CRANKSHAFT A
-
53B2-00032-0 * CRANKSHAFT B* CRANKSHAFT B
-
63B2-00033-0 * CRANKSHAFT C* CRANKSHAFT C
-
73B2-00034-0 * CRANKSHAFT D* CRANKSHAFT D
-
83B2-00061-2 * CRANK PIN* CRANK PIN
-
9350-00062-0 * SEALING PLUG
Crankshaft D* SEALING PLUG
Crankshaft D -
103B2-00051-0 * OIL SEAL 25-47-7* OIL SEAL 25-47-7
-
11369-00115-0 * THRUST PLATE* THRUST PLATE
-
129603-3-6204 * BALL BEARING 6204
Center* BALL BEARING 6204
Center -
139603-3-6204 BALL BEARING 6204
Upper, LowerBALL BEARING 6204
Upper, Lower -
14338-00042-0 ROLLER BEARING 14-18-19
Small EndROLLER BEARING 14-18-19
Small End -
15101-00121-0 OIL SEAL 20-35-7OIL SEAL 20-35-7
-
163B2-87130-0 PISTON REPAIR KIT
STDPISTON REPAIR KIT
STD -
163B2-87131-0 PISTON REPAIR KIT (0.5 O/S)
OPTPISTON REPAIR KIT (0.5 O/S)
OPT -
173B2-00001-1 * PISTON
STD* PISTON
STD -
173B2-00004-1 * PISTON (0.5 O/S)
OPT* PISTON (0.5 O/S)
OPT -
183B2-00021-1 PISTON PINPISTON PIN
-
19350-00024-1 PISTON PIN CLIPPISTON PIN CLIP
-
203G0-87123-0 PISTON RING SET
STDPISTON RING SET
STD -
203G0-87124-0 PISTON RING SET (0.5 O/S)
OPTPISTON RING SET (0.5 O/S)
OPT -
213B2-00011-0 * PISTON RING
STD* PISTON RING
STD -
213B2-00014-0 * PISTON RING (0.5 O/S)
OPT* PISTON RING (0.5 O/S)
OPT
