GEAR CASE для Tohatsu M6B - 2016 года выпуска
-
№АртикулНазвание
-
13B2Q60000-2 GEAR CASE ASSY"GEAR CASE ASSY"
-
23B2-60211-0 * ROLLER BEARING 15-21-16"* ROLLER BEARING 15-21-16"
-
39601-0-6204 BALL BEARING 6204"BALL BEARING 6204"
-
49161E3-0635 BOLT"BOLT"
-
59401E3-0600 WASHER"WASHER"
-
6332-60005-2 PLUG 8-8"PLUG 8-8"
-
7332-60006-0 GASKET 8.1-15-1"GASKET 8.1-15-1"
-
83V1-60217-0 TRIM TAB"TRIM TAB"
-
9910103-5620 BOLT"BOLT"
-
103AA-60206-0 WATER STRAINER W=17"
Mark AWATER STRAINER W=17"
Mark A -
11921503-0430 SCREW"SCREW"
-
12930403-0400 NYLON NUT 4-P0.7"NYLON NUT 4-P0.7"
-
133B2Q60100-1 PROPELLER SHAFT HOUSING ASSY"PROPELLER SHAFT HOUSING ASSY"
-
14345-65015-0 * O-RING 3.2-47"* O-RING 3.2-47"
-
15369-60111-0 * OIL SEAL 15-28-10"* OIL SEAL 15-28-10"
-
169601-0-6004 * BALL BEARING 6004"* BALL BEARING 6004"
-
179101E3-5620 BOLT"BOLT"
-
183B2-64010-0 BEVEL GEAR ASSY (A)BEVEL GEAR ASSY (A)
-
193B2-64020-0 BEVEL GEAR B"BEVEL GEAR B"
-
203B2-64030-0 BEVEL GEAR C"BEVEL GEAR C"
-
21369-64032-0 WASHER 15.2-19-1.9"WASHER 15.2-19-1.9"
-
22369-64014-0 SHIM 21-28-0.1"SHIM 21-28-0.1"
-
22369-64015-0 SHIM 21-28-0.15"SHIM 21-28-0.15"
-
233V1-64211-1 PROPELLER SHAFT"PROPELLER SHAFT"
-
243B2-64215-0 CLUTCH"CLUTCH"
-
25301-64217-0 PIN 3.5-28"PIN 3.5-28"
-
263V1-64221-0 SPRING"SPRING"
-
27369-64223-0 PUSH ROD"PUSH ROD"
-
283B2-64222-0 SPRING RETAINER"SPRING RETAINER"
-
293B2-65021-1 WATER PUMP IMPELLER"WATER PUMP IMPELLER"
-
303B2-65022-0 KEY ?3-11"KEY ?3-11"
-
313B2-65016-0 PUMP CASE (UPPER)PUMP CASE (UPPER)
-
323B2-65011-0 PUMP CASE LINER"PUMP CASE LINER"
-
33331-65014-0 WATER PIPE SEAL (LOWER)WATER PIPE SEAL (LOWER)
-
343B2-65018-2 PUMP CASE GASKET"PUMP CASE GASKET"
-
353B2-65025-0 WATER PUMP GUIDE PLATE"WATER PUMP GUIDE PLATE"
-
363B2-65029-2 GUIDE PLATE GASKET"GUIDE PLATE GASKET"
-
379161E3-0650 BOLT"BOLT"
-
38940103-0600 WASHER"WASHER"
-
393V1-65017-0 PUMP CASE (LOWER)PUMP CASE (LOWER)
-
40309-60111-0 OIL SEAL 12-24-8"OIL SEAL 12-24-8"
-
413B2-65020-1 PUMP CASE GASKET (LOWER)PUMP CASE GASKET (LOWER)
-
423B2-64081-0 SHIM 28-36.8-0.1"SHIM 28-36.8-0.1"
-
423B2-64082-0 SHIM 28-36.8-0.15"SHIM 28-36.8-0.15"
-
423B2-64083-0 SHIM 28-36.8-0.3"SHIM 28-36.8-0.3"
-
433B2-64306-1 DRIVE SHAFT ASSY (S)
for Transom "S"DRIVE SHAFT ASSY (S)
for Transom "S" -
433B2-64307-1 DRIVE SHAFT ASSY (L)
for Transom "L"DRIVE SHAFT ASSY (L)
for Transom "L" -
449601-0-6301 BALL BEARING 6301"BALL BEARING 6301"
-
45369-66011-0 CLUTCH CAM"CLUTCH CAM"
-
46951403-0310 SPRING PIN 3-10"SPRING PIN 3-10"
-
473B2-66012-0 CAM ROD (S)
for Transom "S"CAM ROD (S)
for Transom "S" -
473B2-66013-0 CAM ROD (L)
for Transom "L"CAM ROD (L)
for Transom "L" -
48369-66031-0 CAM ROD BUSHING"CAM ROD BUSHING"
-
49369-66021-1 O-RING 2.5-4.9"O-RING 2.5-4.9"
-
50332-66032-0 O-RING 2.4-15.4"O-RING 2.4-15.4"
-
51369-66033-0 STOPPER"STOPPER"
-
52910103-5625 BOLT"BOLT"
-
533B2-65100-0 WATER PIPE (S)
for Transom "S"WATER PIPE (S)
for Transom "S" -
533B2-65110-0 WATER PIPE (L)
for Transom "L"WATER PIPE (L)
for Transom "L" -
543B2-65195-0 GROMMET 14-2"GROMMET 14-2"
-
553B2B64513-1 PROPELLER ASSY (6.5")
OPT 3 x 216 x 165PROPELLER ASSY (6.5")
OPT 3 x 216 x 165 -
553B2B64514-1 PROPELLER ASSY (7")
M6/8B"L" STD 3 x 226 x 178PROPELLER ASSY (7")
M6/8B"L" STD 3 x 226 x 178 -
553B2B64515-1 PROPELLER ASSY (7.5")
M9.8B "L"&"UL" STD 3 x 216 x 190PROPELLER ASSY (7.5")
M9.8B "L"&"UL" STD 3 x 216 x 190 -
553B2B64517-1 PROPELLER ASSY (8.5")
M6/8/9.8B "S" STD 3 x 226 x 211PROPELLER ASSY (8.5")
M6/8/9.8B "S" STD 3 x 226 x 211 -
553B2B64519-1 PROPELLER ASSY (9.5")
OPT 3 x 226 x 255PROPELLER ASSY (9.5")
OPT 3 x 226 x 255 -
563V1-87326-1 PROPELLER HARDWARE KIT"PROPELLER HARDWARE KIT"
-
573B2-64230-2 * THRUST HOLDER ASSY"* THRUST HOLDER ASSY"
-
58369-64124-0 * WASHER 10.5-28-2"* WASHER 10.5-28-2"
-
59369-64121-0 * PROPELLER NUT"* PROPELLER NUT"
-
60951503-0318 * SPLIT PIN 3-18"* SPLIT PIN 3-18"
