GEAR CASE (DRIVE SHAFT) для Tohatsu M40C - 2003 года выпуска`

№

Артикул

Название
1

361S60000-0 Gear Case

Gear Case

0 ₽
1

345-60211-0 * Needle Bearing. 22~30-30

* Needle Bearing. 22~30-30

4 020 ₽
2

910113-5840 Bolt

Bolt

230 ₽
3

332-60005-2 Oil Plug

Oil Plug

1 050 ₽
4

332-60006-0 Gasket, 8.1-15-1

Gasket, 8.1-15-1

200 ₽
5

345-60206-0 Water Strainer

Water Strainer

410 ₽
6

921503-0440 Screw

Screw

140 ₽
7

930406-0400 Nylon Nut, 4P-0.7

Nylon Nut, 4P-0.7

150 ₽
8

345-64301-0 Drive Shaft “S”
for Transom "S"

Drive Shaft “S”
for Transom "S"

37 110 ₽
12

345-64302-0 Drive Shaft “L”
for Transom "L"

Drive Shaft “L”
for Transom "L"

38 430 ₽
12

345-64303-0 Drive Shaft "UL"
for fransom “UL"

Drive Shaft "UL"
for fransom “UL"

23 970 ₽
9

345-60213-0 Bearing, 32304

Bearing, 32304

5 060 ₽
10

345-64020-1 Bevel Gear l，B"

Bevel Gear l，B"

14 370 ₽
11

345-64025-0 Bolt, Bevel Gear "B"

Bolt, Bevel Gear "B"

2 120 ₽
12

345-64081-0 Shim, 41-51.5-0.1

Shim, 41-51.5-0.1

750 ₽
12

345-64082-0 Shim, 41-51.5-0.15

Shim, 41-51.5-0.15

270 ₽
12

345-64083-0 Shim, 41-51.5-0.3

Shim, 41-51.5-0.3

680 ₽
12

345-64084-0 Shim, 41-51.5-0.5

Shim, 41-51.5-0.5

780 ₽
13

332-65022-0 Key, Pump Impeller

Key, Pump Impeller

1 430 ₽
14

345-65021-0 Impeller, Water Pump

Impeller, Water Pump

4 200 ₽
15

348-65016-1 Pump Case Upper

Pump Case Upper

5 300 ₽
16

348-65011-0 Liner, Pump Case

Liner, Pump Case

980 ₽
17

348-65017-1 Pump Case Lower

Pump Case Lower

5 860 ₽
18

332-60111-0 Oil Seal, 17-33-9.5

Oil Seal, 17-33-9.5

1 600 ₽
19

345-65015-0 O-Ring, 3.2-47

O-Ring, 3.2-47

360 ₽
20

348-65025-0 Guide Plate, Water Pump

Guide Plate, Water Pump

680 ₽
21

348-65029-1 Gasket, Pump Guide Plate

Gasket, Pump Guide Plate

680 ₽
22

348-65018-0 Gasket, Pump Case Upper

Gasket, Pump Case Upper

500 ₽
23

334-65012-0 Knock, 4~10

Knock, 4~10

720 ₽
24

910113-5652 Bolt

Bolt

210 ₽
25

3B7-65014-0 Seal Rubber Lower, Water Pipe

Seal Rubber Lower, Water Pipe

750 ₽
26

345-65206-0 Seal Rubber Upper, Water Pipe

Seal Rubber Upper, Water Pipe

360 ₽
27

345-65205-0 Set Ring, Seal Rubber

Set Ring, Seal Rubber

400 ₽
28

345-65204-0 Lock Rubber, Water Pipe
for Transom "S”

Lock Rubber, Water Pipe
for Transom "S”

770 ₽
28

346-65204-0 Lock Rubber, Water Pipe
for Transom "L", "UL"

Lock Rubber, Water Pipe
for Transom "L", "UL"

480 ₽
29

345-65100-1 Water Pipe “S”
for Transom "S"

Water Pipe “S”
for Transom "S"

1 340 ₽
29

345-65110-1 Water Pipe "L"
for Transom "L"

Water Pipe "L"
for Transom "L"

1 940 ₽
29

345-65120-1 Water Pipe "UL"
for Transom "UL"

Water Pipe "UL"
for Transom "UL"

1 840 ₽
30

348-66011-0 Clutch Cam

Clutch Cam

7 780 ₽
31

348-66012-0 Cam Rod “S”
for Transom "S"

Cam Rod “S”
for Transom "S"

1 190 ₽
31

348-66013-0 Cam Rod "L"
for Transom "L"

Cam Rod "L"
for Transom "L"

1 500 ₽
31

348-66014-0 Cam Rod "UL"
forn Transom "UL"

Cam Rod "UL"
forn Transom "UL"

1 670 ₽
32

951403-0316 Spring Pin, 3~16

Spring Pin, 3~16

210 ₽
33

345-66031-1 Bushing, Cam Rod

Bushing, Cam Rod

1 910 ₽
34

345-66021-0 O-Ring,1.9-6.8

O-Ring,1.9-6.8

290 ₽
35

332-66032-0 O-Ring, 2.4-15.4

O-Ring, 2.4-15.4

320 ₽
36

301-66024-1 Stopper, Cam Rod Bushing

Stopper, Cam Rod Bushing

250 ₽
37

301-66025-0 Gasket, 6.2-11-1

Gasket, 6.2-11-1

240 ₽
38

345-66241-0 Joint, Shift Rod

Joint, Shift Rod

800 ₽
39

951403-0312 Spring Pin, 3-12

Spring Pin, 3-12

300 ₽
