ASSEMBLY KIT для Tohatsu M40C - 2003 года выпуска`
-
№АртикулНазвание
-
13C1B87100-0 Engine Short Block (New)
# 032986XD- Crankshaft Clockwise ScrewEngine Short Block (New)
# 032986XD- Crankshaft Clockwise Screw -
1361B87100-0 Engine Short Block (Old)
〜# 028121XD Crankshaft Counterclockwise ScrewEngine Short Block (Old)
〜# 028121XD Crankshaft Counterclockwise Screw -
2361-87123-0 Piston Ring Set (Std)Piston Ring Set (Std)
-
2361-00011-0 * Piston Ring 1 st (Std)* Piston Ring 1 st (Std)
-
2345-00011-0 * Piston Ring 2nd (Std)* Piston Ring 2nd (Std)
-
2361-87124-0 Piston Ring Set (0.5mm O/S)Piston Ring Set (0.5mm O/S)
-
2361-00014-0 * Piston Ring 1st (0.5mm O/S)* Piston Ring 1st (0.5mm O/S)
-
2345-00014-0 * Piston Ring 2nd (0.5mm O/S)* Piston Ring 2nd (0.5mm O/S)
-
3345-87122-0 Carburetor Repair KitCarburetor Repair Kit
-
3345-02011-0 * Gasket, Carburetor* Gasket, Carburetor
-
3336-03293-0 * O-Ring
Drain Screw* O-Ring
Drain Screw -
3336-03222-0 * O-Ring, 1.9-64
Float Chamber* O-Ring, 1.9-64
Float Chamber -
3922503-6412 * Screw* Screw
-
3334-03231-1 * Float* Float
-
3334-03232-0 * Arm Pin, Float* Arm Pin, Float
-
33B7-03240-0 * Float Valve* Float Valve
-
3345-03243-0 * O-Ring,1.3-5.7
Valve Seat* O-Ring,1.3-5.7
Valve Seat -
3334-03242-0 * Valve Pin* Valve Pin
-
3344-03244-0 * Clip* Clip
-
3346-03265-0 * Stop Screw* Stop Screw
-
3345-03266-0 * Adjust Screw* Adjust Screw
-
4361-87121-1 Power Head Gasket SetPower Head Gasket Set
-
4345-01005-0 * Gasket, Cylinder Head* Gasket, Cylinder Head
-
4346-01032-0 * Gasket, Thermostat* Gasket, Thermostat
-
4345-02305-0 * Gasket, Exhaust Cover* Gasket, Exhaust Cover
-
4126-00121-0 * Oil Seal, 30-45-8
Upper side* Oil Seal, 30-45-8
Upper side -
4345-00122-0 * Oil Seal, 25-55-10
Lower side* Oil Seal, 25-55-10
Lower side -
4338-01403-0 * O-Ring, 2-55.5
Magneto Base* O-Ring, 2-55.5
Magneto Base -
4345-02104-0 * Gasket "A", Inlet Manifold* Gasket "A", Inlet Manifold
-
4345-02105-0 * Gasket "B"，Inlet Manifold* Gasket "B"，Inlet Manifold
-
4345-02011-0 * Gasket, Carburetor* Gasket, Carburetor
-
4336-03293-0 * O-Ring
Drain Screw* O-Ring
Drain Screw -
4336-03222-0 * O-Ring,1.9-64
Float Chamber* O-Ring,1.9-64
Float Chamber -
4346-04901-0 * Gasket, Fuel Pump* Gasket, Fuel Pump
-
4346-02235-0 * Gasket
Fuel Filter* Gasket
Fuel Filter -
4350-05136-0 * O-Ring, 2.5-4.5
Starter Handle* O-Ring, 2.5-4.5
Starter Handle -
4345-61012-0 * Gasket. Drive Shaft Housing* Gasket. Drive Shaft Housing
-
4345-01303-0 * Gasket, Engine Basement* Gasket, Engine Basement
-
4345-01215-0 * Oil Seal, 17-30-8
Drive Shaft* Oil Seal, 17-30-8
Drive Shaft -
5398S63003-0 Handle AssyHandle Assy
-
6361S63000-3 Handle KitHandle Kit
-
6398S63003-0 * Handle Assy* Handle Assy
-
6346-63201-1 * Bolt* Bolt
-
6345-63207-0 * Collar, 9.8-12-7.5* Collar, 9.8-12-7.5
-
6346-63064-0 * Universal Pinion* Universal Pinion
-
6348-63061-0 * Throttle Shaft "B"* Throttle Shaft "B"
-
6951403-0414 * Spring Pin, 4-14* Spring Pin, 4-14
-
6346-63066-1 * Collar, 15.9-17.1-9* Collar, 15.9-17.1-9
-
6940103-0800 * Washer
or 940113-0800* Washer
or 940113-0800 -
6345-63063-0 * Supporter, Throttle Shaft "B"* Supporter, Throttle Shaft "B"
-
6910114-0630 * Bolt* Bolt
-
6940103-0600 * Washer
or 940113-0600* Washer
or 940113-0600 -
6345-66226-0 * Grommet, Throttle Shaft* Grommet, Throttle Shaft
-
6348-63715-0 * Link Rod, 5-75L* Link Rod, 5-75L
-
6930106-0500 * Nut* Nut
-
63B7-63733-0 * Rod Snap, 5-3* Rod Snap, 5-3
-
6346-05234-0 * Ø 5 Rod Joint* Ø 5 Rod Joint
-
6361-83728-0 * Cable Pin* Cable Pin
-
6930106-0600 * Nut* Nut
-
6353-83719-0 * Washer, 8.5-18-1.6* Washer, 8.5-18-1.6
-
6951603-0800 * R-Pin, d二8* R-Pin, d二8
-
7361S87301-0 Lower Unit Ass'y 5
For Transom "S"Lower Unit Ass'y 5
For Transom "S" -
7361S87302-0 Lower Unit Ass'y *"L"
For Transom "L"Lower Unit Ass'y *"L"
For Transom "L" -
8345S60100-0 Propeller Shaft Housing Ass'y
old part No. 345S87323-0Propeller Shaft Housing Ass'y
old part No. 345S87323-0 -
'9361-87322-0 Water Pump Repair KitWater Pump Repair Kit
-
'9345-65021-0 * Impeller, Water Pump* Impeller, Water Pump
-
'9332-65022-0 * Key, Water Pump Impeller* Key, Water Pump Impeller
-
'9348-65011-0 * Liner, Pump Case* Liner, Pump Case
-
'9348-65025-0 * Guide Plate, Water Pump* Guide Plate, Water Pump
-
'9348-65029-1 * Gasket, Pump Guide Plate* Gasket, Pump Guide Plate
-
'9348-65018-0 * Gasket, Pump Case Upper* Gasket, Pump Case Upper
-
'9910113-5652 * Bolt* Bolt
-
10361-65231-0 Chrome Plate Water Pump KitChrome Plate Water Pump Kit
-
10345-65021-0 * Impeller, Water Pump* Impeller, Water Pump
-
10361-65238-0 * Liner, Pump Case* Liner, Pump Case
-
10361-65239-0 * Guide Plate, Water Pump* Guide Plate, Water Pump
-
10348-65029-1 * Gasket, Pump Guide Plate* Gasket, Pump Guide Plate
-
10348-65018-0 * Gasket, Pump Case Upper* Gasket, Pump Case Upper
-
11361-87321-0 Lower Unit Gasket SetLower Unit Gasket Set
-
11332-60006-0 * Gasket, 8.2-14-1* Gasket, 8.2-14-1
-
11345-60103-0 * O-Ring, 3.53-69.44
Propeller Shaft* O-Ring, 3.53-69.44
Propeller Shaft -
11334-60223-0 * Oil Seal, 22-36-10
Propeller Shaft* Oil Seal, 22-36-10
Propeller Shaft -
11332-60111-0 * Oil Seal, 17-33-9.5
Pump Case Lower* Oil Seal, 17-33-9.5
Pump Case Lower -
11345-65015-0 * O-Ring, 3.2-47
Pump Case Lower* O-Ring, 3.2-47
Pump Case Lower -
11348-65029-1 * Gasket, Pump Guide Plate* Gasket, Pump Guide Plate
-
11348-65018-0 * Gasket, Pump Case Upper* Gasket, Pump Case Upper
-
11345-66021-0 * O-Ring,1.9-6.8
Cam Rod* O-Ring,1.9-6.8
Cam Rod -
11332-66032-0 * O-Ring, 2.4-15.4
Bushing* O-Ring, 2.4-15.4
Bushing -
11301-66025-0 * Gasket, 6.2-11~1
Bushing Stopper* Gasket, 6.2-11~1
Bushing Stopper -
12348S87314-0 Extension Housing Kit "UL"Extension Housing Kit "UL"
-
12345S61110-0 * Extension Housing "UL"* Extension Housing "UL"
-
12910113-5840 * Bolt* Bolt
-
12345-64303-0 * Drive Shaft "UL"* Drive Shaft "UL"
-
12345-65120-1 * Water Pipe "UL"* Water Pipe "UL"
-
12348-66014-0 * Cam Rod "UL"* Cam Rod "UL"
-
13361S87801-1 * Decal Set* Decal Set
-
14361-76100-1 Electric Starter Kit (P type)
old part No. 361-76000-1Electric Starter Kit (P type)
old part No. 361-76000-1 -
14346-76010-0 * Starter Motor* Starter Motor
-
14916103-0830 * Bolt* Bolt
-
14345-06971-0 * Clamp, 9-12U* Clamp, 9-12U
-
14930103-0800 * Nut
or 930113-0800* Nut
or 930113-0800 -
14941303-0800 * Spring Washer* Spring Washer
-
14346-76040-0 * Starter Solenoid* Starter Solenoid
-
14361-76055-0 * Bracket, Choke Solenoid* Bracket, Choke Solenoid
-
14345-76081-0 * Bracket, Neutral Switch* Bracket, Neutral Switch
-
14910103-0618 * Bolt* Bolt
-
14930113-0600 * Nut* Nut
-
14941303-0600 * Spring Washer* Spring Washer
-
143G2-76060-0 * Rectifier* Rectifier
-
143G2-76142-0 * Ground Cable
L=100* Ground Cable
L=100 -
14921503-0525 * Screw* Screw
-
14930103-0500 * Nut* Nut
-
14941303-0500 * Spring Washer* Spring Washer
-
14353-06281-0 * Holder, Cable Terminal* Holder, Cable Terminal
-
14353-06283-0 * Collar, 6.4-10-4.7* Collar, 6.4-10-4.7
-
14910103-0620 * Bolt
or 910113-0620* Bolt
or 910113-0620 -
14309-06972-0 * Clamp, 6.5-47.5P* Clamp, 6.5-47.5P
-
14941303-0600 * Spring Washer* Spring Washer
-
14930103-0600 * Nut
or 930113-0600* Nut
or 930113-0600 -
14910103-0645 * Bolt
or 910103-6645* Bolt
or 910103-6645 -
14941303-0600 * Spring Washer
or 910103-6645* Spring Washer
or 910103-6645 -
14128-02605-1 * Spacer, 6-8-28.5* Spacer, 6-8-28.5
-
14910903-6616 * Bolt* Bolt
-
143B2-76062-0 * Fuse Wire
L=355* Fuse Wire
L=355 -
143B2-76120-0 * Battery Cord
「2000* Battery Cord
「2000 -
14334-76141-0 * Ground Cable
「150* Ground Cable
「150 -
14910103-0612 * Bolt
or 910113-0612* Bolt
or 910113-0612 -
143B2-76147-1 * Starter Cord
L=200* Starter Cord
L=200 -
143A3-76145-0 * Cap, Cord* Cap, Cord
-
14336-76091-0 * Band, Lead Wire* Band, Lead Wire
-
143B7-76145-0 * Cap, Cord* Cap, Cord
-
14361-76050-0 * Choke Solenoid* Choke Solenoid
-
14346-76057-0 * Hook, Choke Solenoid* Hook, Choke Solenoid
-
14951403-0312 * Spring Pin, 3-12* Spring Pin, 3-12
-
14346-76072-1 * Rod, Chock Shaft* Rod, Chock Shaft
-
14930406-0400 * Nylon Nut, 4P-0.7* Nylon Nut, 4P-0.7
-
14921503-6408 * Screw* Screw
-
15361-76300-0 Electric Starter Kit (F type)Electric Starter Kit (F type)
-
15346-76010-0 * Starter Motor* Starter Motor
-
15916103-0830 * Bolt* Bolt
-
15345-06971-0 * Clamp, 9-12U* Clamp, 9-12U
-
15930103-0800 * Nut
or 930113-0800* Nut
or 930113-0800 -
15941303-0800 * Spring Washer* Spring Washer
-
15346-76040-0 * Starter Solenoid* Starter Solenoid
-
15361-76055-0 * Bracket, Choke Solenoid* Bracket, Choke Solenoid
-
15361-76080-0 * Neutral Switch* Neutral Switch
-
153M4-76084-0 * Spacer, Neutral Switch* Spacer, Neutral Switch
-
153B7-63731-0 * Washer, 12.5-24-1* Washer, 12.5-24-1
-
15398-76083-0 * Actuator, Neutral Switch* Actuator, Neutral Switch
-
15361-76082-0 * Plate, Neutral Switch* Plate, Neutral Switch
-
15910103-0645 * Bolt
or 910103-6645* Bolt
or 910103-6645 -
15941303-0600 * Spring Washer
or 910103-6645* Spring Washer
or 910103-6645 -
15128-02605-1 * Spacer, 6-8-28.5* Spacer, 6-8-28.5
-
15910903-6616 * Bolt* Bolt
-
153B2-76062-0 * Fuse Wire
L 二 355* Fuse Wire
L 二 355 -
153B2-76120-0 * Battery Cord
L二2000* Battery Cord
L二2000 -
15334-76141-0 * Ground Cable
L二150* Ground Cable
L二150 -
15910103-0612 * Bolt
or 910113-0612* Bolt
or 910113-0612 -
153B2-761477 * Starter Cord
L 二 200* Starter Cord
L 二 200 -
153A3-76145-0 * Cap, Cord* Cap, Cord
-
15336-76091-0 * Band, Lead Wire* Band, Lead Wire
-
153B7-76145-0 * Cap, Cord* Cap, Cord
-
15361-76026-0 * Main Switch* Main Switch
-
15345-76081-0 * Bracket, Neutral Switch* Bracket, Neutral Switch
-
15910103-0618 * Bolt* Bolt
-
15930113-0600 * Nut* Nut
-
15941303-0600 * Spring Washer* Spring Washer
-
153G2-76060-0 * Rectifier* Rectifier
-
153G2-76142-0 * Ground Cable
L=100* Ground Cable
L=100 -
15921503-0525 * Screw* Screw
-
15930103-0500 * Nut* Nut
-
15941303-0500 * Spring Washer* Spring Washer
-
15353-06281-0 * Holder, Cable Terminal* Holder, Cable Terminal
-
15353-06283-0 * Collar, 6.4-10-4.7* Collar, 6.4-10-4.7
-
15910103-0620 * Bolt* Bolt
-
15309-06972-0 * Clamp, 6.5-47.5P* Clamp, 6.5-47.5P
Все узлы модели:
- CYLINDER CRANK CASE
- PISTON CRANK SHAFT
- INLET REED VALVE
- CARBURETOR
- FUEL PUMP
- THROTTLE MECHANISM
- TILLER HANDLE
- MAGNETO
- ELECTRIC STARTER (STARTER MOTOR)
- ELECTRIC STARTER (EXCLUSIVE USE FOR EP TYPE)
- RECOIL STARTER
- STARTER LOCK
- DRIVE SHAFT HOUSING
- GEAR CASE (DRIVE SHAFT)
- GEAR CASE( PROPELLER SHAFT)
- SHIFT
- BRACKET
- REVERSE LOCK
- MOTOR COVER
- SEPARATE FUEL TANK (PLASTIC) ACCESSORIES
- OPTIONAL PARTS (1) REMOTE CONTROL (P TYPE)
- OPTIONAL PARTS (2) METER)
- OPTIONAL PARTS (3) ACCESSORIES
- • ASSEMBLY KIT
