FRAME COVER (GRAY/BLACK-RED/BLACK) для Suzuki GSX-R750 - 2018 года выпуска
-
№АртикулНазвание
-
1-147100-15J10-44X COVER, FRAME (RH) (44X - BLACK FOR AV4 - RED/BLACK)COVER, FRAME (RH) (44X - BLACK FOR AV4 - RED/BLACK)
-
1-247100-15J10-ATX COVER, FRAME (RH) (ATX - BLACK FOR BD7 - GRAY/BLACK)COVER, FRAME (RH) (ATX - BLACK FOR BD7 - GRAY/BLACK)
-
247611-14J00 ...COVER, FRAME...COVER, FRAME
-
3-168131-15J00-AV4 ...EMBLEM "750" (AV4 - RED/BLACK FOR COVER 44X FOR BIKE AV4 - RED/BLACK)...EMBLEM "750" (AV4 - RED/BLACK FOR COVER 44X FOR BIKE AV4 - RED/BLACK)
-
3-268131-15J00-ARB ...EMBLEM "750" (ARB - RED/BLACK FOR COVER ATX FOR BIKE BD7 - GRAY/BLACK)...EMBLEM "750" (ARB - RED/BLACK FOR COVER ATX FOR BIKE BD7 - GRAY/BLACK)
-
494443-06G00 ...TAPE (6X25X0.13)...TAPE (6X25X0.13)
-
503541-0512A ...SCREW...SCREW
-
6-147200-15J10-44X COVER, FRAME (LH) (44X - BLACK FOR AV4 - RED/BLACK)COVER, FRAME (LH) (44X - BLACK FOR AV4 - RED/BLACK)
-
6-247200-15J10-ATX COVER, FRAME (LH) (ATX - BLACK FOR BD7 - GRAY/BLACKCOVER, FRAME (LH) (ATX - BLACK FOR BD7 - GRAY/BLACK
-
747621-14J00 ...COVER, FRAME...COVER, FRAME
-
8-168131-15J00-AV4 ...EMBLEM "750" (AV4 - RED/BLACK FOR COVER 44X FOR BIKE AV4 - RED/BLACK)...EMBLEM "750" (AV4 - RED/BLACK FOR COVER 44X FOR BIKE AV4 - RED/BLACK)
-
8-268131-15J00-ARB ...EMBLEM "750" (ARB - RED/BLACK FOR COVER ATX FOR BIKE BD7 - GRAY/BLACK...EMBLEM "750" (ARB - RED/BLACK FOR COVER ATX FOR BIKE BD7 - GRAY/BLACK
-
994443-06G00 ...TAPE (6X25X0.13)...TAPE (6X25X0.13)
-
1003541-0512A ...SCREW...SCREW
-
1147300-14J00 COVER, FRAME CENTERCOVER, FRAME CENTER
-
1248128-14FA0 ...CUSHION...CUSHION
-
1394443-06G00 ...TAPE...TAPE
-
1447312-37H00 CUSHION, CENTERCUSHION, CENTER
-
1509136-06056 SCREW (6X16)SCREW (6X16)
-
1609159-05019 NUTNUT
-
1709180-06283 SPACER (6.5X10X7)SPACER (6.5X10X7)
-
1809320-06504 CUSHIONCUSHION
-
1909409-06314-5PK CLIP (BLACK)CLIP (BLACK)
-
2002142-1520B SCREWSCREW
