SIDE COVER для Suzuki GSX-R1000 K2 - 2002 года выпуска

  • №
    Артикул
    Название
  • 1-1
    47100-40F10-CT5 COVER, FRAME ASSY. (CT5 - SILVER/BLACK) (FOR L99 - WHITE/BLUE)
    COVER, FRAME ASSY. (CT5 - SILVER/BLACK) (FOR L99 - WHITE/BLUE)
  • 1-2
    47100-40F20-FP2 COVER, FRAME ASSY. (FP2 - SILVER/BLACK) (FOR M4L - BLACK/RED)
    COVER, FRAME ASSY. (FP2 - SILVER/BLACK) (FOR M4L - BLACK/RED)
  • 1-3
    47100-40F20-CY9 COVER, FRAME ASSY. (CY9 - BLACK/SILVER) (FOR FH9 - BLUE/BLACK)
    COVER, FRAME ASSY. (CY9 - BLACK/SILVER) (FOR FH9 - BLUE/BLACK)
  • 2-1
    68135-40F20-1LE ...TAPE, (RIGHT) (1LE - BLUE) (FOR L99 - WHITE/BLUE)
    ...TAPE, (RIGHT) (1LE - BLUE) (FOR L99 - WHITE/BLUE)
  • 2-2
    68135-40F20-Y7M ...TAPE, (RIGHT) (Y7M - RED) (FOR M4L - BLACK/RED)
    ...TAPE, (RIGHT) (Y7M - RED) (FOR M4L - BLACK/RED)
  • 2-3
    68135-40F20-YC2 ...TAPE, (RIGHT) (BLUE) (YC2 - BLUE) (FOR FH9 - BLUE/BLACK)
    ...TAPE, (RIGHT) (BLUE) (YC2 - BLUE) (FOR FH9 - BLUE/BLACK)
  • 3-1
    68145-40F20-1LE ...TAPE, (LEFT) (1LE - BLUE) (FOR L99 - WHITE/BLUE)
    ...TAPE, (LEFT) (1LE - BLUE) (FOR L99 - WHITE/BLUE)
  • 3-2
    68145-40F20-Y7M ...TAPE, (LEFT) (Y7M - RED) (FOR M4L - BLACK/RED)
    ...TAPE, (LEFT) (Y7M - RED) (FOR M4L - BLACK/RED)
  • 3-3
    68145-40F20-YC2 ...TAPE, (LEFT) (BLUE) (YC2 - BLUE) (FOR FH9 - BLUE/BLACK)
    ...TAPE, (LEFT) (BLUE) (YC2 - BLUE) (FOR FH9 - BLUE/BLACK)
  • 4
    68131-40F00-FS8 ...EMBLEM, "1000" (FS8 - BLACK/ORANGE) (FOR L99 - WHITE/BLUE)
    ...EMBLEM, "1000" (FS8 - BLACK/ORANGE) (FOR L99 - WHITE/BLUE)
  • 5-1
    68131-40F10-HU1 ...EMBLEM, "1000" (HU1 - WHITE/BLACK) (FOR M4L - BLACK/RED)
    ...EMBLEM, "1000" (HU1 - WHITE/BLACK) (FOR M4L - BLACK/RED)
  • 5-2
    68131-40F10-HU2 ...EMBLEM, "1000" (HU2 - WHITE/BLACK) (FOR FH9 - BLUE/BLACK)
    ...EMBLEM, "1000" (HU2 - WHITE/BLACK) (FOR FH9 - BLUE/BLACK)
  • 6-1
    68131-39F00-0JW ...EMBLEM, "SUZUKI" (OJW - WHITE) (FOR L99 - WHITE/BLUE)
    ...EMBLEM, "SUZUKI" (OJW - WHITE) (FOR L99 - WHITE/BLUE)
  • 6-2
    68131-39F00-YD8 ...EMBLEM, "SUZUKI" (YD8 - SILVER) (FOR M4L - BLACK/RED, FH9 - BLUE/BLACK)
    ...EMBLEM, "SUZUKI" (YD8 - SILVER) (FOR M4L - BLACK/RED, FH9 - BLUE/BLACK)
  • 7
    09139-06042 SCREW, (FRONT)
    SCREW, (FRONT)
  • 8
    09160-06047 WASHER
    WASHER
  • 9
    09180-06283 SPACER
    SPACER
  • 10
    47161-35F00 CUSHION, (FRONT)
    CUSHION, (FRONT)
  • 11
    09139-06029 SCREW, (SIDE)
    SCREW, (SIDE)
  • 12
    09160-06047 WASHER
    WASHER
  • 13
    09180-06283 SPACER
    SPACER
  • 14
    47161-35F10 CUSHION, (SIDE)
    CUSHION, (SIDE)
  • 15
    09139-06029 SCREW, UPPER
    SCREW, UPPER
  • 16
    09180-06286 SPACER
    SPACER
  • 17
    09320-10045 CUSHION
    CUSHION
