GEARCASE - INTERNAL COMPONENTS - FRONT для Polaris RANGER CREW 570-6 SAGE GREEN (R18RDA57A1) - 2018 года выпуска

  • №
    Артикул
    Название
  • 1
    1333750 ASSY, FRONT GEARCASE (INCL. 2-14)
    ASSY, FRONT GEARCASE (INCL. 2-14)
  • 2
    3235168 ASSY, COVER OUTPUT (INCL. O-RING, DOWEL PIN, OIL SEAL, COVER, CONNECTOR ASSY, BACKLASH SPACER, 4WD COIL, GROMMET & HEAT SHRINK TUBING)
    ASSY, COVER OUTPUT (INCL. O-RING, DOWEL PIN, OIL SEAL, COVER, CONNECTOR ASSY, BACKLASH SPACER, 4WD COIL, GROMMET & HEAT SHRINK TUBING)
  • 3
    3235169 KIT, HUB ASSY (INCL. BUSHING, HUB SUB. ASSY & NYLON SPACER)
    KIT, HUB ASSY (INCL. BUSHING, HUB SUB. ASSY & NYLON SPACER)
  • 4
    3235170 KIT, FASTENER (INCL. ALL FASTENERS)
    KIT, FASTENER (INCL. ALL FASTENERS)
  • 5
    3235171 KIT, SEAL REPAIR (INCL. ALL SEALS)
    KIT, SEAL REPAIR (INCL. ALL SEALS)
  • 6
    3235485 PLATE, ARMATURE
    PLATE, ARMATURE
  • 7
    3235174 BEARING, PINION (INCL. ALL BEARINGS)
    BEARING, PINION (INCL. ALL BEARINGS)
  • 8
    3235624 K-CLUTCH ROLLS (INCL. COMPLETE SET OF ROLLER)
    K-CLUTCH ROLLS (INCL. COMPLETE SET OF ROLLER)
  • 9
    3235917 ASM-ROLL CAGE (INCL. ROLL CAGE & SPRING WIRE FOR H-CLIP)
    ASM-ROLL CAGE (INCL. ROLL CAGE & SPRING WIRE FOR H-CLIP)
  • 10
    3235440 KIT, GEARCASE ASSY (INCL. HOSE FITTING, BUSHING, SEAL, GEARCASE, FILL PLUG & DRAIN PLUG)
    KIT, GEARCASE ASSY (INCL. HOSE FITTING, BUSHING, SEAL, GEARCASE, FILL PLUG & DRAIN PLUG)
  • 11
    2203738 PLUG, DRAIN
    PLUG, DRAIN
  • 12
    2203739 PLUG, FILL
    PLUG, FILL
  • 13
    3235711 KIT, GEAR HOUSING & PINION (INCL. RING GEAR ASSY, PINION, BEARING, INTERNAL RING & SHAFT RING)
    KIT, GEAR HOUSING & PINION (INCL. RING GEAR ASSY, PINION, BEARING, INTERNAL RING & SHAFT RING)
  • 14
    3235712 KIT, SPRING (INCL. TORSION SPRING & SPRINT RETAINER ASSY)
    KIT, SPRING (INCL. TORSION SPRING & SPRINT RETAINER ASSY)
