REAR SUSPENSION для Polaris RANGER 400 MIDSIZE SAGE GREEN (R13RH45AG) - 2013 года выпуска

  • №
    Артикул
    Название
  • 1
    7519043 BOLT
    BOLT
  • 2
    7547333 NUT, NYLOK
    NUT, NYLOK
  • 3
    5137591 SHAFT, PIVOT
    SHAFT, PIVOT
  • 4
    5439270 BUSHING, A-ARM., SHORT, BLACK
    BUSHING, A-ARM., SHORT, BLACK
  • 5
    5251753 RETAINER, SHOCK
    RETAINER, SHOCK
  • 6
    7518563 BOLT, FLANGE
    BOLT, FLANGE
  • 7
    7080510 FITTING, ZERK
    FITTING, ZERK
  • 8
    7043548 SHOCK, REAR
    SHOCK, REAR
  • 9
    7043891-458 SPRING, REAR, MATTE BLACK
    SPRING, REAR, MATTE BLACK
  • 10
    5253768 CAM, ADJUSTING, SPRING
    CAM, ADJUSTING, SPRING
  • 11
    1018189-458 ARM, CONTROL, UPPER, MATTE BLACK
    ARM, CONTROL, UPPER, MATTE BLACK
  • 12
    5137592 SHAFT, PIVOT
    SHAFT, PIVOT
  • 13
    7512365 SCREW (REAR CALIPER ATTACH)
    SCREW (REAR CALIPER ATTACH)
  • 14
    7518562 BOLT
    BOLT
  • 15
    1018190-458 ARM, CONTROL, LOWER, MATTE BLACK
    ARM, CONTROL, LOWER, MATTE BLACK
  • 16
    5134741 CARRIER, BEARING, WHEEL, LEFT HAND
    CARRIER, BEARING, WHEEL, LEFT HAND
  • 16
    5134531 CARRIER, BEARING, WHEEL, RIGHT HAND
    CARRIER, BEARING, WHEEL, RIGHT HAND
  • 17
    3514635 BEARING, CARRIER, WHEEL
    BEARING, CARRIER, WHEEL
  • 18
    7710440 RING, RETAINING
    RING, RETAINING
  • 19
    7518566 BOLT
    BOLT
  • 20
    5137593 SHAFT, PIVOT
    SHAFT, PIVOT
  • 21
    7552901 WASHER, SPRING LOCK (REAR CALIPER ATTACH)
    WASHER, SPRING LOCK (REAR CALIPER ATTACH)
  • 22
    7558402 WASHER, FLAT (REAR CALIPER ATTACH)
    WASHER, FLAT (REAR CALIPER ATTACH)
  • 23
    5334945 SPACER
    SPACER
  • 24
    7518610 BOLT
    BOLT
