SUSPENSION - IFS SHOCK (7044388) для Polaris 800 SWITCHBACK ADVENTURE 137 ES (S18DDE8PSL) - 2018 года выпуска`
-
№АртикулНазвание
-
-1501190 KIT, REBUILD, ZERO 1.5KIT, REBUILD, ZERO 1.5
-
-7044388 SHOCK, IFSSHOCK, IFS
-
11500902 BUMPERBUMPER
-
21500103 BUSHING, EYELETBUSHING, EYELET
-
31501103 BUSHING, EYELETBUSHING, EYELET
-
41500016 NUT, LOCKNUT, LOCK
-
51500011 SCREWSCREW
-
61501012 DECAL, BAND, PERF. SERIESDECAL, BAND, PERF. SERIES
-
71501104 DECAL, RES., PERF., SERIESDECAL, RES., PERF., SERIES
-
81501105 DECAL, BASE VALVE, 3 POS.DECAL, BASE VALVE, 3 POS.
-
91500108 O-RING, .103W-1.549IDO-RING, .103W-1.549ID
-
101500623 O-RINGO-RING
-
111500097 RING, RET., WIRERING, RET., WIRE
-
121501015 RING, RET., WIRERING, RET., WIRE
-
131501117 BODY CAP, PIGGYBACKBODY CAP, PIGGYBACK
-
141501118 BODY, .498X8.60TLGBODY, .498X8.60TLG
-
151501108 KNOB, DAMP. ADJ.KNOB, DAMP. ADJ.
-
161500852 SLEEVESLEEVE
-
171500889 EYELET, SHAFTEYELET, SHAFT
-
181501119 RESERVOIR, BLACKRESERVOIR, BLACK
-
191501120 SHAFT, .498X9.4TLGSHAFT, .498X9.4TLG
-
201501121 SPACER, SHAFTSPACER, SHAFT
-
211500895 RING, PRELOAD, BACK-UPRING, PRELOAD, BACK-UP
-
221500894 RING, PRELOADRING, PRELOAD
-
231500930 GUIDE, SPRINGGUIDE, SPRING
-
241500896 WASHERWASHER
-
251501112 PISTON, FLTG, W/O-RINGPISTON, FLTG, W/O-RING
-
261501027 ASM., END CAP, RESERVOIRASM., END CAP, RESERVOIR
-
271501113 ASM., BRNG. CAP, W/O-RINGASM., BRNG. CAP, W/O-RING
-
281501114 ASM., BEARING, FISTASM., BEARING, FIST
-
291501116 ASM., DAMP. ADJASM., DAMP. ADJ
-
305020618 RETAINER, SPRING, SLOTTEDRETAINER, SPRING, SLOTTED
-
317043732-133 SPRG-COMP .306X11.0 80# WHTSPRG-COMP .306X11.0 80# WHT
