FUEL TANK для Polaris 550 VOYAGEUR 144 ES (INDY RED) (S18CEF5BSL) - 2018 года выпуска

  • №
    Артикул
    Название
  • 1
    2521225 ASM., FUEL TANK (INCL. 3-4)
    ASM., FUEL TANK (INCL. 3-4)
  • 2
    2520815 CAP, FUEL TANK W/GAUGE
    CAP, FUEL TANK W/GAUGE
  • 3
    7515136 SCREW
    SCREW
  • 4
    5247431 BRACKET, SEAT MOUNT
    BRACKET, SEAT MOUNT
  • 5
    7547453 NUT, NYLOK
    NUT, NYLOK
  • 6
    7555935 WASHER
    WASHER
  • 7
    7520464 SCREW-SPCL
    SCREW-SPCL
  • 8
    5813874 PAD, GAS TANK, LEFT HAND
    PAD, GAS TANK, LEFT HAND
  • 8
    5813875 PAD, GAS TANK, RIGHT HAND
    PAD, GAS TANK, RIGHT HAND
  • 9
    8450126-104 LINE, VENT, 5/16 ID, 104 CM
    LINE, VENT, 5/16 ID, 104 CM
  • 10
    5813729 PAD, RUBBER
    PAD, RUBBER
  • 11
    7052215 PICK-UP FUEL W/MESH
    PICK-UP FUEL W/MESH
  • 12
    7080768 RING, COMPRESSION
    RING, COMPRESSION
  • 13
    8350020-160 LINE, FUEL, 3/8 IN
    LINE, FUEL, 3/8 IN
  • 14
    5435941 GROMMET, VITON-3/4 IN
    GROMMET, VITON-3/4 IN
  • 15
    7052455 FITTING, 90 DEGREE
    FITTING, 90 DEGREE
