ENGINE MOUNTING W/ SHORT BLOCK для Polaris 600 IQ TOURING AND EURO (S09PT6HS/HE) - 2009 года выпуска

  • №
    Артикул
    Название
  • 1
    2203601 KIT-SHT BLACK S3468-6044-PU6H (SEE NOTE)
    KIT-SHT BLACK S3468-6044-PU6H (SEE NOTE)
  • 2
    3021354 STOP-TORQUE, COURSE, 3/8-16 1.50
    STOP-TORQUE, COURSE, 3/8-16 1.50
  • 3
    7542404 NUT
    NUT
  • 4
    1015359 WELD-TORQUE STOP
    WELD-TORQUE STOP
  • 5
    7517854 SCR-3/8-16X1-P30-SPEC-Y
    SCR-3/8-16X1-P30-SPEC-Y
  • 6
    1015415 WELD-TORQUE STOP/ENGINE MOUNT
    WELD-TORQUE STOP/ENGINE MOUNT
  • 7
    1015202 WELD-NUT PLATE, REAR
    WELD-NUT PLATE, REAR
  • 8
    7661637 RIVET, INTERLOCK, Z
    RIVET, INTERLOCK, Z
  • 9
    3021717 ISOLATOR-RUBBER
    ISOLATOR-RUBBER
  • 10
    5135856 STRAP-ENGINE MNT, LEFT HAND, SDI
    STRAP-ENGINE MNT, LEFT HAND, SDI
  • 11
    7518644 SCR-M10X1.50X35 HX/FL
    SCR-M10X1.50X35 HX/FL
  • 12
    5413303 MOUNT-ENGINE RUBBER, BOTTOM 3/8
    MOUNT-ENGINE RUBBER, BOTTOM 3/8
  • 13
    5413350 MOUNT-ENGINE RUBBER TOP, 3/8
    MOUNT-ENGINE RUBBER TOP, 3/8
  • 14
    1016001 ASM- CLINCH NUT PLATE
    ASM- CLINCH NUT PLATE
  • 15
    7555915 WASHER, FLAT
    WASHER, FLAT
  • 16
    7555893 WASHER, FLAT
    WASHER, FLAT
  • 17
    7542451 NUT, NYLOK
    NUT, NYLOK
  • 18
    7518782 BOLT3/8-16X2.25HXCSGR8-Y, SPPT
    BOLT3/8-16X2.25HXCSGR8-Y, SPPT
  • 19
    5135326 STRAP-ENGINE, RIGHT HAND, MACH
    STRAP-ENGINE, RIGHT HAND, MACH
  • 20
    7517632 SCREW
    SCREW
  • 21
    7555936 WASHER (10)*
    WASHER (10)*
