DRIVE TRAIN ASSEMBLY W/ DRIVE BELT для Polaris WIDETRAK LX AND EURO (S08SU4BS) - 2008 года выпуска`
-
№АртикулНазвание
-
17713401 RING, RETAININGRING, RETAINING
-
27555922 BUSHING, MACH.,BUSHING, MACH.,
-
31911317 ASM-BRAKE DISCASM-BRAKE DISC
-
57517291 BOLTBOLT
-
65410630 O-RINGO-RING
-
77517446 SCREWSCREW
-
81332219 COUPLER ASM, 19T, W/GREASE, LONG (INCL. FITTING & SCREW)COUPLER ASM, 19T, W/GREASE, LONG (INCL. FITTING & SCREW)
-
87080437 ZERK, GREASEZERK, GREASE
-
91332256 ASM-JACKSHAFT, LONG KEY (INCL. 10)ASM-JACKSHAFT, LONG KEY (INCL. 10)
-
103514525 BEARINGBEARING
-
117542324 NUT, NYLOKNUT, NYLOK
-
127558402 WASHER, FLATWASHER, FLAT
-
135222393 FLANGETTE (2-BOLT)FLANGETTE (2-BOLT)
-
145830135 GASKET, JACKSHAFT, 2-BOLTGASKET, JACKSHAFT, 2-BOLT
-
155222647 FLANGETTE, (GREASABLE)FLANGETTE, (GREASABLE)
-
167512377 BOLT, CARRIAGEBOLT, CARRIAGE
-
177556509 BUSHINGBUSHING
-
187721132 KEY-1/4 X 3/16 X 2.25KEY-1/4 X 3/16 X 2.25
-
205431482 SPACER, INLET SHAFTSPACER, INLET SHAFT
-
217555806 WASHER, FLATWASHER, FLAT
-
227515502 BOLTBOLT
-
237571626 WASHER, SPRINGWASHER, SPRING
-
243211070 BELT, DRIVE, 28 DEG.BELT, DRIVE, 28 DEG.
-
253280116 ADAPTER, DRIVE, W/ZERKADAPTER, DRIVE, W/ZERK
-
257080433 FITTING, LUBRICATION, THREADED(10FITTING, LUBRICATION, THREADED(10
-
265830012 GASKET, DRIVE ADAPTORGASKET, DRIVE ADAPTOR
-
273280017 KEY, SPEEDOMETER, SQUAREKEY, SPEEDOMETER, SQUARE
-
285243529 FLANGETTE-OFFSET, W/HOLEFLANGETTE-OFFSET, W/HOLE
-
293280019 BUSHING METAL SPEEDOBUSHING METAL SPEEDO
-
301012945 ASM.-FLANGETTE W/SCREWSASM.-FLANGETTE W/SCREWS
-
311590450 ASM-DRIVESHAFT, WIDETRAK (INCL. 29, 31)ASM-DRIVESHAFT, WIDETRAK (INCL. 29, 31)
-
321332260 ASM-COUPLER, 19T, W/GREASE ZERKASM-COUPLER, 19T, W/GREASE ZERK
-
327080437 ZERK, GREASEZERK, GREASE
-
337517292 BOLTBOLT
-
347518360 BOLT-CARR 3/8-16X3.5 GR5-YBOLT-CARR 3/8-16X3.5 GR5-Y
-
355210760 SPACER-.080SPACER-.080
-
355210759 SPACER-.063SPACER-.063
-
355210764 SPACER-.020SPACER-.020
-
355211065 SHIM, .010SHIM, .010
-
367542423 NUT, FLANGENUT, FLANGE
-
373514448 BEARING-25MM SPH OD LUBEBEARING-25MM SPH OD LUBE
