SUSPENSION - REAR TORQUE ARM ASSEMBLY для Polaris WIDETRAK LX AND EURO (S08SU4BS) - 2008 года выпуска
-
№АртикулНазвание
-
17517435 SCREWSCREW
-
27552603 WASHER, SPRING LOCKWASHER, SPRING LOCK
-
37555893 WASHER, FLATWASHER, FLAT
-
45134040 SHAFT-.750X20.19SHAFT-.750X20.19
-
57041240-067 SPRING, RIGHT HAND, RIGHT HANDSUSP, BLACK.SPRING, RIGHT HAND, RIGHT HANDSUSP, BLACK.
-
65521277 SPACER, SPRINGSPACER, SPRING
-
77542451 NUT, NYLOKNUT, NYLOK
-
81541979-329 WELD-REAR TORQUE ARM, ECOATWELD-REAR TORQUE ARM, ECOAT
-
97515317 BOLTBOLT
-
107542326 NUT, SHOULDERNUT, SHOULDER
-
117542302 NUT LOCKNUT LOCK
-
127041239-067 SPRING, LEFT HAND, RIGHT HANDSUSP, BLACK.SPRING, LEFT HAND, RIGHT HANDSUSP, BLACK.
-
137080221 BOLT-EYE, SPRING ADJ.BOLT-EYE, SPRING ADJ.
-
147555823 WASHERWASHER
-
155132239 SHAFT-PIVOT, .750X13.235SHAFT-PIVOT, .750X13.235
-
161540652-067 ARM, RIGHT HANDPIVOT, BLACK.ARM, RIGHT HANDPIVOT, BLACK.
-
177080424 FITTING, LUBRICATIONFITTING, LUBRICATION
