OIL PUMP для Polaris SUPERSPORT AND EURO (S08NP5BS/BE) - 2008 года выпуска
-
№АртикулНазвание
-
13083141 CLAMP-HOSECLAMP-HOSE
-
23087114 TUBETUBE
-
33084467 ASM., PIPE, VINYL, 90MMASM., PIPE, VINYL, 90MM
-
43085157 PIPE, VINYL (INCL. 1)PIPE, VINYL (INCL. 1)
-
53083125 SCREW-AIR VENTSCREW-AIR VENT
-
63083126 PACKINGPACKING
-
73087185 PIPE-VINYLPIPE-VINYL
-
83089223 ASM-OIL PUMP (INCL. 5, 6, 9-13, 19)ASM-OIL PUMP (INCL. 5, 6, 9-13, 19)
-
93089228 SPRING RETURNSPRING RETURN
-
103083445 COLLAR, CAMSHAFTCOLLAR, CAMSHAFT
-
113089227 LEVER CONTROLLEVER CONTROL
-
123083121 WASHER-SPRINGWASHER-SPRING
-
133083120 NUTNUT
-
143087277 CRANKSHAFT-1(MAG SIDE)CRANKSHAFT-1(MAG SIDE)
-
153083131 GEAR, SMALLGEAR, SMALL
-
163083130 SPACERSPACER
-
173083353 BUSHINGBUSHING
-
183083671 SPACER 1, .15MMSPACER 1, .15MM
-
183083672 SPACER 2, .3MMSPACER 2, .3MM
-
183083673 SPACER 3, .6MMSPACER 3, .6MM
-
193083127 O RINGO RING
-
205813237 GASKET-OIL PUMP, 550GASKET-OIL PUMP, 550
