CONSOLE для Polaris WIDETRAK LX AND EURO (S07SU4BS/BE) - 2007 года выпуска

  • №
    Артикул
    Название
  • 1
    7517263 SCREW, HX/SEMS
    SCREW, HX/SEMS
  • 2
    4010794 REGULATOR-AC/DC 14.3V
    REGULATOR-AC/DC 14.3V
  • 3
    7555746 WASHER
    WASHER
  • 4
    7541925 NUT, NYLOK 10-24 Y
    NUT, NYLOK 10-24 Y
  • 5
    7080138 CABLE TIE
    CABLE TIE
  • 6
    4020057 HOUSING
    HOUSING
  • 7
    2461145 HARNESS-MAIN WIRE
    HARNESS-MAIN WIRE
  • 8
    7515199 SCREW
    SCREW
  • 9
    2200358 KIT, IGN.SWITCH
    KIT, IGN.SWITCH
  • 10
    7080290 CABLE, CHOKE (INCL. 11, 19)
    CABLE, CHOKE (INCL. 11, 19)
  • 11
    5432943 KIT, CHOKE LEVER REPAIR (INCL. PIN)
    KIT, CHOKE LEVER REPAIR (INCL. PIN)
  • 12
    7080804 CABLE TIE-RELEASABLE, 5 1/2''
    CABLE TIE-RELEASABLE, 5 1/2''
  • 13
    7555932 WASHER, NYLON
    WASHER, NYLON
  • 14
    7621330 RIVET, POP
    RIVET, POP
  • 15
    5243049 GUIDE-RECOIL
    GUIDE-RECOIL
  • 16
    7080761 CABLE TIE, 14''
    CABLE TIE, 14''
  • 17
    5433243 BOOT-HANDLEBAR
    BOOT-HANDLEBAR
  • 18
    7571610 WASHER-LOCK
    WASHER-LOCK
  • 19
    5432944 NUT, CHOKE
    NUT, CHOKE
  • 20
    5410611 KEY (SEE NOTE)
    KEY (SEE NOTE)
  • 21
    7547035 NUT, IGNITION
    NUT, IGNITION
  • 22
    4110263 SWITCH, HEATER, HI/LO
    SWITCH, HEATER, HI/LO
  • 22
    7661124 HAIRPIN-COTTER 3/16-1/4
    HAIRPIN-COTTER 3/16-1/4
  • 23
    5432994 CONSOLE, HYB.BLACK
    CONSOLE, HYB.BLACK
