STEERING ASSEMBLY для Polaris 600 TRIUMPH (S00SB6AS) - 2000 года выпуска
-
№АртикулНазвание
-
17542103 NUT, LOCKNUT, LOCK
-
21012887-067 STEERING HOOP, SHORT (BLK)STEERING HOOP, SHORT (BLK)
-
37080138 STRAP PANDUITSTRAP PANDUIT
-
41820648-067 STEERING POST (BLK)STEERING POST (BLK)
-
57080804 CABLE TIE-RELEASABLE (5 1/2'')CABLE TIE-RELEASABLE (5 1/2'')
-
67517377 SCREWSCREW
-
77661638 RIVET, INTERLOCK, BRIVET, INTERLOCK, B
-
87542303 NUT FLEX LOCNUT FLEX LOC
-
97542403 NUT LOCKNUT LOCK
-
107080433 ZERK, FITTING, THREADEDZERK, FITTING, THREADED
-
117512404 BOLTBOLT
-
121822266 STEERING ASSY (CENTER) (INCL. 10, 22)STEERING ASSY (CENTER) (INCL. 10, 22)
-
135010463 BUSHINGBUSHING
-
147555721 WASHERWASHER
-
157542703 NUT FLEX,NUT FLEX,
-
167060165 ROD END (RIGHT)ROD END (RIGHT)
-
177542424 NUTNUT
-
185332712 ROD, DRAG LINKROD, DRAG LINK
-
197542401 NUT HEXAGONNUT HEXAGON
-
207060164 ROD END (LEFT)ROD END (LEFT)
-
217661203 PIN COTTERPIN COTTER
-
223563907 BUSHINGBUSHING
-
237621340 RIVETRIVET
-
245211454-067 PLATE, BOOTSEAT (BLK)PLATE, BOOTSEAT (BLK)
-
255411122 BOOT, TIEROD (LEFT)BOOT, TIEROD (LEFT)
-
267555735 WASHER, WAVEWASHER, WAVE
-
277512682 BOLTBOLT
-
285630563 BLOCK, STEERING (CAST)BLOCK, STEERING (CAST)
-
294020139 CLIP, PLASTICCLIP, PLASTIC
-
305411123 BOOT, TIEROD, (RIGHT)BOOT, TIEROD, (RIGHT)
-
315211453-067 PLATE, BOOTSEAL (RIGHT/BLK)PLATE, BOOTSEAL (RIGHT/BLK)
-
327060174 ROD END (RIGHT) (3/8) (HI-ANGLE)ROD END (RIGHT) (3/8) (HI-ANGLE)
-
335020859-067 ROD, TIE (BLK).ROD, TIE (BLK).
-
345521131 TRIM, EDGE (6FT) (BLK)TRIM, EDGE (6FT) (BLK)
-
357512275 BOLT CARRIAGEBOLT CARRIAGE
-
367517428 BOLTBOLT
-
377061005 ROD END (LEFT) (3/8) (HI-ANGLE)ROD END (LEFT) (3/8) (HI-ANGLE)
