SEAT W/ GAS TANK ASSEMBLY для Polaris 600 TRIUMPH (S00SB6AS) - 2000 года выпуска
-
№АртикулНазвание
-
12511248 CAP, GAS, W/GAUGECAP, GAS, W/GAUGE
-
15810513 GASKET, GAS CAPGASKET, GAS CAP
-
25410842 GROMMET, FUELTANKGROMMET, FUELTANK
-
37080550 GROMMET, RELATCH, 1'' (BOTTOM)GROMMET, RELATCH, 1'' (BOTTOM)
-
47080549 GROMMET, RELATCH, 1'' (TOP)GROMMET, RELATCH, 1'' (TOP)
-
57080548 TWISTLOCK, RELATCH, 1'', W/HOLETWISTLOCK, RELATCH, 1'', W/HOLE
-
67621337 RIVETRIVET
-
74030024 BULB, TAILLIGHTBULB, TAILLIGHT
-
85430423 LENS, TAILLIGHTLENS, TAILLIGHT
-
97511840 SCREWSCREW
-
104030045 BULB, BRAKELIGHTBULB, BRAKELIGHT
-
112682412 COVER ASSY, SEAT, LONGCOVER ASSY, SEAT, LONG
-
112682493 CUSHION, SEAT ASSY (INCL. 3-28, 31, 32)CUSHION, SEAT ASSY (INCL. 3-28, 31, 32)
-
127080559 CABLE, TANK, RETENTIONCABLE, TANK, RETENTION
-
132460398 HARNESS, TAILLIGHTHARNESS, TAILLIGHT
-
145243185 RETAINER-CLIP, TOOL POUCHRETAINER-CLIP, TOOL POUCH
-
157621472 RIVETRIVET
-
167555746 BURR, RIVETBURR, RIVET
-
177670097 CLIP, DART,CLIP, DART,
-
187542147 NUT, RETAINER WELDNUT, RETAINER WELD
-
195433341 HOUSING TAILLIGHTHOUSING TAILLIGHT
-
205431436 COVER, TAILLIGHT PROTECTORCOVER, TAILLIGHT PROTECTOR
-
217621301 RIVETRIVET
-
227512242 SCREWSCREW
-
237621464 RIVETRIVET
-
247052243 FUEL PICKUP, W/FILTERFUEL PICKUP, W/FILTER
-
257080402 RING, COMPRESSIONRING, COMPRESSION
-
268350019-600 FUELLINE, ESTERFUELLINE, ESTER
-
277541925 NUTNUT
-
287052023 FITTING OUTLETFITTING OUTLET
-
297080307 CLAMPCLAMP
-
308350018-600 TUBING, ETHER ERETHNE (160CM)TUBING, ETHER ERETHNE (160CM)
-
318450061-600 FUELLINE (3MMX7MM)FUELLINE (3MMX7MM)
-
327052095 FITTING (30 DEG) (1/8)FITTING (30 DEG) (1/8)
