FUEL TANK для Polaris Virage i 3-Pass Euro - 2003 года выпуска`
-
№АртикулНазвание
-
15244279 BRACKET, STRAP 5/16 BOLTBRACKET, STRAP 5/16 BOLT
-
27552610 WASHER, LOCKWASHER, LOCK
-
37515361 BOLTBOLT
-
45243775 HOOK, STRAP NARROWHOOK, STRAP NARROW
-
55430621 STRAPSTRAP
-
65434871 TANK, OILTANK, OIL
-
75243776 HOOK, STRAP 180 DEG RETURNHOOK, STRAP 180 DEG RETURN
-
85410424 STRAP, BATTERY HOLDDOWNSTRAP, BATTERY HOLDDOWN
-
92520177 CAP, FUEL RATCHET ASSY.CAP, FUEL RATCHET ASSY.
-
107080710 CHAIN, BEADCHAIN, BEAD
-
117511873 SCREWSCREW
-
127080442 COUPLING, ENDCOUPLING, END
-
135433553 INLET, FUELINLET, FUEL
-
145811492 SEAL, FUEL INLETSEAL, FUEL INLET
-
155433621 NUT, INLET FUELNUT, INLET FUEL
-
167080766 CLAMP, HOSECLAMP, HOSE
-
175411757 HOSE, FUEL FILLHOSE, FUEL FILL
-
187080451 CLAMP, HOSECLAMP, HOSE
-
195433259 NUTNUT
-
202410129 PUMP, FUEL ELECTRICPUMP, FUEL ELECTRIC
-
215411636 GASKETGASKET
-
227621407 RIVETRIVET
-
235812206 PAD, FUEL TANK STOPPAD, FUEL TANK STOP
-
245244758 BRACKET, FUEL TANK STOPBRACKET, FUEL TANK STOP
-
255812152 PAD, EVA (26''X5''X.22)PAD, EVA (26''X5''X.22)
-
265434872 TANK, FUEL LETTER W/RELIEF DFITANK, FUEL LETTER W/RELIEF DFI
-
277621229 RIVETRIVET
-
285411305 SEAL, FUEL CAPSEAL, FUEL CAP
