THROTTLE BODY ASSY. для Polaris Virage i 3-Pass Euro - 2003 года выпуска
-
№АртикулНазвание
-
17516816 SCREWSCREW
-
25631090 BASE, INTAKE SILENCER DFIBASE, INTAKE SILENCER DFI
-
35830062 GASKET, CARBURETOR (UPPER)GASKET, CARBURETOR (UPPER)
-
41253430 THROTTLE BODY ASSY.THROTTLE BODY ASSY.
-
57080138 CABLE TIECABLE TIE
-
67516603 BOLTBOLT
-
77080539 CLAMP, NYLON CABLECLAMP, NYLON CABLE
-
85521663-09 HOSEHOSE
-
97080138 CABLE TIECABLE TIE
-
107516606 SCREWSCREW
-
112410379 TPS, ELECTRO OVERMOLD KITTPS, ELECTRO OVERMOLD KIT
-
127042274 SPRING, TORSION ELECTROSPRING, TORSION ELECTRO
-
135434096 COUPLER, ELECTROCOUPLER, ELECTRO
-
142410299 SENSOR, AIR TEMP DFISENSOR, AIR TEMP DFI
