FUEL SYSTEM для Polaris Virage i 3-Pass Euro - 2003 года выпуска
-
№АртикулНазвание
-
15410682 GROMMET, VENTGROMMET, VENT
-
27080483 CABLE TIE (4 IN.)CABLE TIE (4 IN.)
-
37051015 VALVE, CHECK RELIEFVALVE, CHECK RELIEF
-
48450104-1525 FUEL LINE (1/4'', 250CM) (OPT)FUEL LINE (1/4'', 250CM) (OPT)
-
57052111 FITTING, TEEFITTING, TEE
-
67080138 CABLE TIECABLE TIE
-
77052118 VALVE, VACUUM CHECKVALVE, VACUUM CHECK
-
87080476 CLAMP, HOSECLAMP, HOSE
-
97052253 CONNECTOR ASSY.CONNECTOR ASSY.
-
107080482 T, CLIPT, CLIP
-
117052230 FITTING, T-FICHT LARGEFITTING, T-FICHT LARGE
-
127080830 CLAMP, HOSECLAMP, HOSE
-
137052229 FITTING, L-FICHT LARGEFITTING, L-FICHT LARGE
-
145411601 O-RING, DFI FITTING LARGEO-RING, DFI FITTING LARGE
-
157052227 FITTING, L-FICHT SMALLFITTING, L-FICHT SMALL
-
165411599 O-RING, DFI FITTING SMALLO-RING, DFI FITTING SMALL
-
171253375 INJECTORINJECTOR
-
187052228 FITTING, T-FICHT SMALLFITTING, T-FICHT SMALL
-
192872602 SHRADER, VALVE FICHT W/CAPSHRADER, VALVE FICHT W/CAP
-
207052329 FITTING, 1/4'' STRAIGHTFITTING, 1/4'' STRAIGHT
