ELECTRICAL BOX для Polaris Octane - 2003 года выпуска

‹-+›
  • №
    Артикул
    Название
  • 1
    2461087 HARNESS, CIRCUT BREAKER/SOL.
    HARNESS, CIRCUT BREAKER/SOL.
  • 2
    2461091 HARNESS, START STOP CONTROLS
    HARNESS, START STOP CONTROLS
  • 3
    7080464 ANCHOR, CABLE TIE
    ANCHOR, CABLE TIE
  • 4
    7080138 CABLE TIE
    CABLE TIE
  • 5
    5410346 INSUL.CABLE SOL.
    INSUL.CABLE SOL.
  • 6
    7546705 NUT
    NUT
  • 7
    7552613 WASHER, LOCK
    WASHER, LOCK
  • 8
    4010858 SOLENOID, STARTER
    SOLENOID, STARTER
  • 9
    7546704 NUT, NYLOK
    NUT, NYLOK
  • 10
    5411456 STRAP
    STRAP
  • 11
    5224472 HOOK, 'D'
    HOOK, 'D'
  • 12
    4060161 FUSE (3 AMP)
    FUSE (3 AMP)
  • 13
    4060111 FUSE,
    FUSE,
  • 14
    2460928 HARNESS, JUMPER
    HARNESS, JUMPER
  • 15
    7517669 SCREW
    SCREW
  • 16
    7555882 WASHER
    WASHER
  • 17
    5246395 BRACKET, E BOX
    BRACKET, E BOX
  • 18
    5432503 ELECTRICAL BOX, PLASTIC ASSY.
    ELECTRICAL BOX, PLASTIC ASSY.
  • 19
    5333544 PIN, LATCH
    PIN, LATCH
  • 20
    4010558 CONTROLLER, IGNITION
    CONTROLLER, IGNITION
  • 21
    2410250 STRAP ASSY., GROUNDING W/FUSES
    STRAP ASSY., GROUNDING W/FUSES
  • 22
    7547061 NUT, NYLOK
    NUT, NYLOK
  • 23
    7555837 WASHER, FLAT
    WASHER, FLAT
  • 24
    7512042 BOLT
    BOLT
  • 25
    4010387 REGULATOR, RECT/CUTOFF
    REGULATOR, RECT/CUTOFF
  • 26
    4010756 CABLE, BATTERY SOLENOID
    CABLE, BATTERY SOLENOID
  • 27
    4010237 CABLE-SOLENOID/STARTER
    CABLE-SOLENOID/STARTER
  • 28
    5411491 O-RING
    O-RING
  • 29
    7080461 BOOT, THREADED (RED)
    BOOT, THREADED (RED)
  • 30
    7515113 BOLT
    BOLT
  • 31
    7555836 WASHER
    WASHER
  • 32
    5432574 PLATE, STATOR 1 HOLE
    PLATE, STATOR 1 HOLE
  • 33
    7073734 DECAL
    DECAL
  • 34
    2460718 HARNESS, 8 WIRE STATOR
    HARNESS, 8 WIRE STATOR
  • 35
    5433119 COVER, ACCESSORY E-BOX
    COVER, ACCESSORY E-BOX
  • 36
    5432569 SEAL
    SEAL
  • 37
    5244370 BRACKET, COIL
    BRACKET, COIL
  • 38
    4010175 COIL, IGNITION
    COIL, IGNITION
  • 39
    2410202 TERMINAL BOARD ASSY.
    TERMINAL BOARD ASSY.
  • 40
    2434011 CIRKUT.BREAKER (15A)
    CIRKUT.BREAKER (15A)
  • 41
    2632137 ELECTRICAL BOX, IGNITION ASSY. (INCL. 18, 19, 35, 36)
    ELECTRICAL BOX, IGNITION ASSY. (INCL. 18, 19, 35, 36)
  • 42
    5411235 GROMMET
    GROMMET
  • 43
    5432502 CAP, GROMMET
    CAP, GROMMET
