CARBURETOR для Polaris Octane - 2003 года выпуска
-
№АртикулНазвание
-
1A1253202 CARBURETOR ASSY.CARBURETOR ASSY.
-
1B2200788 CARBURETOR REBUILD KIT (INCL. 10, 15)CARBURETOR REBUILD KIT (INCL. 10, 15)
-
13050136 SCREWSCREW
-
22200687 FUELPUMP BODY KIT (KEIHIN)FUELPUMP BODY KIT (KEIHIN)
-
32200686 GASKET KIT (FUELPUMP)GASKET KIT (FUELPUMP)
-
43050143 HOSE, FUELHOSE, FUEL
-
57080138 CABLE TIECABLE TIE
-
63050146 JET, BLOCK COMP (REAR)JET, BLOCK COMP (REAR)
-
73050156 JOINT, CONNECTINGJOINT, CONNECTING
-
83050157 TUBE, RUBBERTUBE, RUBBER
-
93050144 SCREEN, FUEL STRAINERSCREEN, FUEL STRAINER
-
102200733 NEEDLE VALVE, 97DOM KIT (1 PER CARB)NEEDLE VALVE, 97DOM KIT (1 PER CARB)
-
113050186 JET-MAIN, 140 KEIHIN (1 PER CARB)JET-MAIN, 140 KEIHIN (1 PER CARB)
-
123050129 JET-PILOT, 68 KEIHINJET-PILOT, 68 KEIHIN
-
133050135 SCREW, JET BLOCK COVERSCREW, JET BLOCK COVER
-
143050139 COVER, JET BLOCKCOVER, JET BLOCK
-
152200730 DIAPHRAGM, JET BLOCK KIT (1 PER CARB)DIAPHRAGM, JET BLOCK KIT (1 PER CARB)
-
163050137 SCREW, JET BLOCKSCREW, JET BLOCK
-
173050147 O-RING, JET BLOCKO-RING, JET BLOCK
-
183050138 COLLARCOLLAR
-
193050148 O-RING, VALVE SEATO-RING, VALVE SEAT
-
202200688 CHECKVALVE, MAIN KIT (KEIHIN) (1 PER CARB)CHECKVALVE, MAIN KIT (KEIHIN) (1 PER CARB)
-
213050140 CAP, LIMITERCAP, LIMITER
-
222200690 MAIN MIX SCREW KIT (KEIHIN) (1 PER CARB)MAIN MIX SCREW KIT (KEIHIN) (1 PER CARB)
-
232200731 IDLESTOP SCREW KITIDLESTOP SCREW KIT
-
243050158 E-CLIPE-CLIP
-
253050152 WASHERWASHER
-
263050153 FENDERFENDER
-
273050154 WASHER, LOCKWASHER, LOCK
-
283050155 NUT, THROTTLE SHAFTNUT, THROTTLE SHAFT
-
292200734 SYNCH. SCREW KITSYNCH. SCREW KIT
-
303050160 PLATE, CONNECTINGPLATE, CONNECTING
-
313050159 SCREW, CONNECTION PLATESCREW, CONNECTION PLATE
