PROPULSION для Polaris SLX 2-Pass - 2000 года выпуска
-
№АртикулНазвание
-
13610043 SEAL, BEARING STATORSEAL, BEARING STATOR
-
23514008 BEARINGBEARING
-
35010294 SPACERSPACER
-
45132088 STATORSTATOR
-
55410817 O-RINGO-RING
-
65410818 O-RINGO-RING
-
75020697 SHAFT, STUBSHAFT, STUB
-
85410735 O-RINGO-RING
-
95432269 PIPE, WATER ENGINEPIPE, WATER ENGINE
-
105131196 EXTENSION, PUMPEXTENSION, PUMP
-
115411107 SEAL, WATER PIPESEAL, WATER PIPE
-
125411016 SEAL, SIPHON TUBESEAL, SIPHON TUBE
-
135431990 TUBE, SIPHONTUBE, SIPHON
-
147542455 NUT, HEXNUT, HEX
-
155241741 BRACKET, STEERING CABLEBRACKET, STEERING CABLE
-
167555941 WASHER, PUMP STUD SEALWASHER, PUMP STUD SEAL
-
175132111 STUD, MOUNT PUMP LONG INT.STUD, MOUNT PUMP LONG INT.
-
185010295 SPACER, IMPELLERSPACER, IMPELLER
-
195132202 IMPELLERIMPELLER
-
208450054-100 HOSE, WATERHOSE, WATER
-
215411644 SEAL, IMPELLER/SHAFTSEAL, IMPELLER/SHAFT
-
227080138 CABLE TIECABLE TIE
-
237522019 SCREWSCREW
-
245630598 BUSHINGBUSHING
-
255131573 HOUSING, PUMP W/O RING INT STUDHOUSING, PUMP W/O RING INT STUD
-
267555966 WASHERWASHER
-
275410652 O-RING, PUMP HOUSING/HULLO-RING, PUMP HOUSING/HULL
-
285811984 SEAL, TAILCONESEAL, TAILCONE
-
295431523 SCREEN, ENGINE INLETSCREEN, ENGINE INLET
-
305432841 WEDGE, PUMPWEDGE, PUMP
-
317515389 BOLTBOLT
-
327555835 WASHER, FLATWASHER, FLAT
-
337552610 WASHER, LOCKWASHER, LOCK
-
347555866 WASHERWASHER
-
355131463 SWIVEL, ROD ENDSWIVEL, ROD END
-
365130938 COLLARCOLLAR
-
377555874 WASHER, FLATWASHER, FLAT
-
387515361 BOLTBOLT
-
395431765 NOZZLE, TRIMNOZZLE, TRIM
-
405130960 NOZZLE, STEERING REVERSENOZZLE, STEERING REVERSE
-
415431518 BEARING, STEERING NOZZLEBEARING, STEERING NOZZLE
-
427515366 BOLTBOLT
-
431350038 NOZZLE ASSY.NOZZLE ASSY.
-
447512064 SCREWSCREW
-
455431519 CONE, PUMPCONE, PUMP
Все узлы модели:
- AIR INTAKE SYSTEM
- BATTERY BOX
- BILGE PUMP
- CARBURETOR
- COOLING SYSTEM
- CRANKCASE
- CRANKSHAFT W/ PISTONS
- CYLINDER W/ INTAKE
- DECALS
- DRIVE SHAFT W/ COUPLER
- ELECTRICAL BOX
- ENGINE FOGGING SYSTEM
- ENGINE MOUNTING W/ SHORT BLOCK
- EXHAUST SYSTEM
- FUEL / WATER SEPARATOR
- FUEL SYSTEM
- FUEL TANK
- HANDLEBAR ASSY. W/ STEERING COLUMN
- HULL
- HULL
- INTAKE GRATE W/ RIDE PLATE
- MAGNETO
- OIL PUMP
- OIL TANK
- • PROPULSION
- SEAT
- STARTING MOTOR
- STEERING CABLE ASSY.
- STORAGE COMPARTMENT - FRONT
- TOOL KIT
- TRIM ASSY.
