ELECTRICAL BOX для Polaris SLX 2-Pass - 2000 года выпуска
-
№АртикулНазвание
-
17512072 SCREWSCREW
-
27547036 NUTNUT
-
37552615 WASHER, LOCKWASHER, LOCK
-
47555837 WASHER, FLATWASHER, FLAT
-
57555870 WASHER, RUBBERWASHER, RUBBER
-
65211761 PLATE, E-BOX (BOTTOM)PLATE, E-BOX (BOTTOM)
-
72460831 HARNESS, WIRE GROUND JUMPERHARNESS, WIRE GROUND JUMPER
-
82460635 HARNESS, TRIM 2 HOLE GROMMETHARNESS, TRIM 2 HOLE GROMMET
-
92460675 HARNESS, 60 INCH (10 WIRE)HARNESS, 60 INCH (10 WIRE)
-
104010122 CABLE, BATTERY (RED)CABLE, BATTERY (RED)
-
114010123 CABLE (RED)CABLE (RED)
-
127080471 T-CLIPT-CLIP
-
135432502 CAP, GROMMETCAP, GROMMET
-
144010302 REGULATOR-RECTIFER CUTOFFREGULATOR-RECTIFER CUTOFF
-
152434014 TERMINAL BOARD ASSY.TERMINAL BOARD ASSY.
-
164010051-05 CONDUIT, CONVOL (15 CM)CONDUIT, CONVOL (15 CM)
-
174010379 CONTROLLER, IGNITIONCONTROLLER, IGNITION
-
185211760 PLATE, E-BOX (TOP)PLATE, E-BOX (TOP)
-
192434011 CIRCUIT BREAKER (15A)CIRCUIT BREAKER (15A)
-
205432503 ELECTRICAL BOX, PLASTIC ASSY.ELECTRICAL BOX, PLASTIC ASSY.
-
215333544 PIN, LATCHPIN, LATCH
-
225224472 HOOKHOOK
-
235410853 STRAP, RUBBERSTRAP, RUBBER
-
245242994 BRACKET, BATTERY STRAPBRACKET, BATTERY STRAP
-
257552613 WASHER, LOCKWASHER, LOCK
-
267512043 BOLTBOLT
-
275242995 BRACKET, BATTERY STRAPBRACKET, BATTERY STRAP
-
285411235 GROMMETGROMMET
-
294010174 COIL, IGNITIONCOIL, IGNITION
-
305432569 SEALSEAL
-
315243538 BRACKET, COIL/SOLENOID (.078 THICK)BRACKET, COIL/SOLENOID (.078 THICK)
-
327547061 NUT, NYLOKNUT, NYLOK
-
334010228 SOLENOID, STARTERSOLENOID, STARTER
-
345410346 INSULATED CABLE SOLENOIDINSULATED CABLE SOLENOID
-
357080461 BOOT, THREADED (RED)BOOT, THREADED (RED)
-
365411491 O-RINGO-RING
-
377073713 DECAL, WARN (HI. VOLT.)DECAL, WARN (HI. VOLT.)
-
382632136 ELECTRICAL BOX, PLASTIC ASSY. (INCL. 20,21,30)ELECTRICAL BOX, PLASTIC ASSY. (INCL. 20,21,30)
-
397077691 DECAL ''RESET ELEC SYSTEM''DECAL ''RESET ELEC SYSTEM''
-
405432574 PLATE, STATOR 1 HOLEPLATE, STATOR 1 HOLE
-
417555836 WASHERWASHER
-
427515113 BOLTBOLT
