CRANKCASE для Polaris SLX 2-Pass - 2000 года выпуска

  • №
    Артикул
    Название
  • 1
    2201562 CRANKCASE KIT (INCL. 15-19)
    CRANKCASE KIT (INCL. 15-19)
  • 2
    3569805 BUSHING
    BUSHING
  • 3
    5433130 PLUG, TIMING HOLE
    PLUG, TIMING HOLE
  • 4
    3574214 BUSHING, PLASTIC
    BUSHING, PLASTIC
  • 5
    7041457 SPRING
    SPRING
  • 6
    3569806 BUSHING
    BUSHING
  • 7
    1201923 COVER, FLYWHEEL ASSY.
    COVER, FLYWHEEL ASSY.
  • 8
    7517676 SCREW
    SCREW
  • 9
    7516806 BOLT
    BOLT
  • 10
    5811550 GASKET, FLYWHEEL COVER
    GASKET, FLYWHEEL COVER
  • 11
    7516723 BOLT
    BOLT
  • 12
    7663002 PIN, DOWEL
    PIN, DOWEL
  • 13
    5411564 O-RING
    O-RING
  • 14
    1201938 FLYWHEEL HOUSING ASSY. (INCL. 2,12)
    FLYWHEEL HOUSING ASSY. (INCL. 2,12)
  • 15
    7517628 BOLT
    BOLT
  • 16
    7051529 PIPE PLUG, BRASS
    PIPE PLUG, BRASS
  • 17
    7516913 BOLT
    BOLT
  • 18
    5131677 STUD, CYLINDER FLANGE (152MM)
    STUD, CYLINDER FLANGE (152MM)
  • 19
    7663001 PIN, DOWEL
    PIN, DOWEL
