GEARCASE для Polaris SPORTSMAN 800 EFI HO (A09MN76AX) (GREEN/BLACK) - 2009 года выпуска

  • №
    Артикул
    Название
  • -
    1332607 ASM-GEARCASE, GEN 2, 2.88H (INCL. ALL)
    ASM-GEARCASE, GEN 2, 2.88H (INCL. ALL)
  • 1
    3233961 NUT-LOCK HEX FLANGE NYLON 5/16
    NUT-LOCK HEX FLANGE NYLON 5/16
  • 2
    3233826 SCREW
    SCREW
  • 3
    3234188 COVER, GEARCASE
    COVER, GEARCASE
  • 4
    3233869 O-RING
    O-RING
  • 5
    3233829 PAWL-DETENT
    PAWL-DETENT
  • 6
    3233831 SHAFT-SHIFT
    SHAFT-SHIFT
  • 7
    3233832 GEAR-SECTOR, 31T-CUT TO 11T
    GEAR-SECTOR, 31T-CUT TO 11T
  • 8
    3233788 SEAL-TRIPLE LIP
    SEAL-TRIPLE LIP
  • 9
    3234143 LABEL-OIL FILL/LEVEL CHECK
    LABEL-OIL FILL/LEVEL CHECK
  • 10
    3233794 PLUG-HEX, HOLLOW, WITH O-RING
    PLUG-HEX, HOLLOW, WITH O-RING
  • 11
    3234358 GEARCASE, MAIN MACH
    GEARCASE, MAIN MACH
  • 12
    3233524 TUBE, VENT
    TUBE, VENT
  • 13
    3233915 PLATE-PARK 12 FACE
    PLATE-PARK 12 FACE
  • 14
    3234221 GEARCASE-LEFT HAND, MACH
    GEARCASE-LEFT HAND, MACH
  • 15
    3233874 SEAL-DUAL LIP
    SEAL-DUAL LIP
  • 16
    3234042 SCREW
    SCREW
  • 17
    3234142 BRACKET-TRANSMISSION MOUNT
    BRACKET-TRANSMISSION MOUNT
  • 18
    3233247 PIN, DOWEL
    PIN, DOWEL
  • 19
    3233839 GEAR-SECTOR, 16T
    GEAR-SECTOR, 16T
  • 20
    3233838 DISC-LOCKOUT
    DISC-LOCKOUT
  • 21
    3234043 NUT
    NUT
  • 22
    3233909 STAR-DETENT
    STAR-DETENT
  • 23
    3233076 O-RING
    O-RING
  • 24
    3234578 SPRING, COMPRESSION DETENT
    SPRING, COMPRESSION DETENT
  • 25
    3233835 SWITCH-ROTARY, 6 PIN
    SWITCH-ROTARY, 6 PIN
  • 26
    3233834 RING-RETAINING
    RING-RETAINING
  • 27
    3234584 BELLCRANK, 510 HOLE, 92 DEGREE
    BELLCRANK, 510 HOLE, 92 DEGREE
  • 28
    3234114 SCR-TAPPING HEX WASHER HD 5/16
    SCR-TAPPING HEX WASHER HD 5/16
  • 29
    1016346 WELD-TORQUE STOP
    WELD-TORQUE STOP
  • 30
    7542440 NUT
    NUT
  • 31
    3021354 STOP-TORQUE, COURSE, 3/8-16 1.50
    STOP-TORQUE, COURSE, 3/8-16 1.50
  • 32
    3234529 PLUG, ѕ-16 HOLLOW HEX MAGNETIC
    PLUG, ѕ-16 HOLLOW HEX MAGNETIC
