GEARCASE - OUTPUT для Polaris SPORTSMAN 800 EFI HO (A09MN76AX) (GREEN/BLACK) - 2009 года выпуска

  • №
    Артикул
    Название
  • -
    1332607 ASM-GEARCASE, GEN 2, 2.88H (INCL. ALL)
    ASM-GEARCASE, GEN 2, 2.88H (INCL. ALL)
  • 1
    3233619 WASHER, THRUST
    WASHER, THRUST
  • 2
    3233019 BEARING
    BEARING
  • 3
    3233873 SPROCKET-22T/18T
    SPROCKET-22T/18T
  • 4
    3233911 SHAFT-OUTPUT, MAIN, REAR
    SHAFT-OUTPUT, MAIN, REAR
  • 5
    3233611 SHIM
    SHIM
  • 6
    3233582 BUTTON, THRUST
    BUTTON, THRUST
  • 7
    3233583 SHIM .450 X .265
    SHIM .450 X .265
  • 8
    3234130 COVER-FRONT OUTPUT, MACH
    COVER-FRONT OUTPUT, MACH
  • 9
    3234114 SCR-TAPPING HEX WASHER HD 5/16
    SCR-TAPPING HEX WASHER HD 5/16
  • 10
    3233788 SEAL-TRIPLE LIP
    SEAL-TRIPLE LIP
  • 11
    3233625 SHAFT, FRONT OUTPUT
    SHAFT, FRONT OUTPUT
  • 12
    3233784 CHAIN-SILENT, REXNORD
    CHAIN-SILENT, REXNORD
  • 13
    3233844 SPROCKET-22T
    SPROCKET-22T
  • 14
    3233552 BUSHING, GARLOCK
    BUSHING, GARLOCK
