CALIPER - REAR для Polaris SCRAMBLER 500 (A09BG50AA) - 2009 года выпуска
-
№АртикулНазвание
-
-1910806 CALIPER ASM, REAR, DH4P, W/INS PD (INCL. 1-6)CALIPER ASM, REAR, DH4P, W/INS PD (INCL. 1-6)
-
12201873 ANVIL BODY-KIT (INCL. ANVIL BODY, BUSHINGS, SNAP RINGS, WASHERS, BOLTS)ANVIL BODY-KIT (INCL. ANVIL BODY, BUSHINGS, SNAP RINGS, WASHERS, BOLTS)
-
22201870 SLIDE BOLT-KIT, DH4P (INCL. SLIDE BOLTS, SLEEVES, O-RINGS, BUSHINGS, CLIPS)SLIDE BOLT-KIT, DH4P (INCL. SLIDE BOLTS, SLEEVES, O-RINGS, BUSHINGS, CLIPS)
-
32201872 SEAL, KIT, DH4P (INCL. DUST BOOT, SQUARE RINGS)SEAL, KIT, DH4P (INCL. DUST BOOT, SQUARE RINGS)
-
42201869 PISTON/SEAL-KIT, DH4P (INCL. PISTON, INSULATOR, SQUARE RINGS, DUST BOOT)PISTON/SEAL-KIT, DH4P (INCL. PISTON, INSULATOR, SQUARE RINGS, DUST BOOT)
-
52202414 KIT-BRAKE PAD ASM, DH4P (INCL. 2 PADS)KIT-BRAKE PAD ASM, DH4P (INCL. 2 PADS)
-
61910538 FITTING-BLEED COMPACTFITTING-BLEED COMPACT
