GEARCASE MOUNTING для Polaris SCRAMBLER 500 4X4 (A03BG50AA) - 2003 года выпуска

  • №
    Артикул
    Название
  • 1
    7517632 SCREW
    SCREW
  • 2
    5132046 MOUNT, TRANSMISSION (REAR)
    MOUNT, TRANSMISSION (REAR)
  • 3
    7547089 NUT
    NUT
  • 4
    7512492 SCREW
    SCREW
  • 5
    7555806 WASHER, FLAT
    WASHER, FLAT
  • 6
    7517646 SCREW
    SCREW
  • 7
    3221041 SPROCKET, SPLINED (13 TEETH)
    SPROCKET, SPLINED (13 TEETH)
  • 8
    7710434 RING, SNAP
    RING, SNAP
  • 9
    5211065 SHIM, GEARCASE (.010) (OPT.)
    SHIM, GEARCASE (.010) (OPT.)
  • 9
    5210764 SPACER (.020) (OPT.)
    SPACER (.020) (OPT.)
  • 9
    5211517 SHIM (.030) (OPT.)
    SHIM (.030) (OPT.)
  • 10
    7517642 SCREW
    SCREW
