ELECTRICAL W/ TAILLIGHT ASSY. для Polaris SPORTSMAN 700 (A02CH68AB) (SPRUCE) - 2002 года выпуска

  • №
    Артикул
    Название
  • 1
    2460936 HARNESS MAIN
    HARNESS MAIN
  • 2
    2410323 BREAKER, CIRCUT (20 AMP)
    BREAKER, CIRCUT (20 AMP)
  • 3
    2432034 TAIL LIGHT ASSY. (INCL. 6-12) (IF BUILT BEFORE 2/01/02)
    TAIL LIGHT ASSY. (INCL. 6-12) (IF BUILT BEFORE 2/01/02)
  • 3
    2410320 TAILLIGHT ASSY. (INCL. 6-12) (IF BUILT AFTER 2/01/02)
    TAILLIGHT ASSY. (INCL. 6-12) (IF BUILT AFTER 2/01/02)
  • 4
    4032045 GASKET, TAILLIGHT
    GASKET, TAILLIGHT
  • 5
    4030043 BULB, TAILLIGHT
    BULB, TAILLIGHT
  • 6
    4032046 LENS, TAILLIGHT
    LENS, TAILLIGHT
  • 7
    4032029 SCREW, TAILLIGHT
    SCREW, TAILLIGHT
  • 8
    7517386 SCREW
    SCREW
  • 9
    5245125-067 STRAP, BATTERY HOLDDOWN (BLACK)
    STRAP, BATTERY HOLDDOWN (BLACK)
  • 10
    4010630 BATTERY, 30 AMP MOUNT (TOP)
    BATTERY, 30 AMP MOUNT (TOP)
  • 11
    4032064 BACKING, TAILLIGHT
    BACKING, TAILLIGHT
  • 12
    7670054 NUT, PUSH-ON
    NUT, PUSH-ON
  • 13
    4010470 CABLE, BLACK 25''
    CABLE, BLACK 25''
  • 14
    2202099 BATTERY BOLT KIT
    BATTERY BOLT KIT
  • 15
    4010471 CABLE, 8.5 BATTERY/SOLENOID (RED)
    CABLE, 8.5 BATTERY/SOLENOID (RED)
  • 16
    7512232 BOLT
    BOLT
  • 17
    7555859 WASHER, FLAT
    WASHER, FLAT
  • 18
    5434037 BOX, BATTERY
    BOX, BATTERY
  • 19
    5432077 TUBE, BATTERY VENT
    TUBE, BATTERY VENT
  • 20
    7512024 SCREW
    SCREW
  • 21
    3083211 SOLENOID
    SOLENOID
  • 22
    4010376 CABLE, SOLENOID/STATER
    CABLE, SOLENOID/STATER
  • 23
    4010657 REGULATOR, RECT
    REGULATOR, RECT
  • 24
    5133182 HEAT, SINK RECT.
    HEAT, SINK RECT.
  • 25
    4020139 CLIP, PLASTIC (SMALL)
    CLIP, PLASTIC (SMALL)
  • 26
    7080138 STRAP, PANDUIT
    STRAP, PANDUIT
  • 27
    7512027 SCREW
    SCREW
