GEAR SELECTOR для Polaris SPORTSMAN 400 (A02CH42AC) (MEDIUM (YELLOW) - 2002 года выпуска

  • №
    Артикул
    Название
  • 1
    3233195 GEAR SELECT KNOB,HLR,BLACK,ASM.
    GEAR SELECT KNOB,HLR,BLACK,ASM.
  • 2
    7512024 SCREW,
    SCREW,
  • 3
    3233649 SCREW
    SCREW
  • 4
    3233131 STRAP, WIRE
    STRAP, WIRE
  • 5
    3233648 COVER-GEAR SELECTOR BOOT
    COVER-GEAR SELECTOR BOOT
  • 6
    3233658 SUBASM-HANDLE GEAR SELECTOR
    SUBASM-HANDLE GEAR SELECTOR
  • 7
    3233646 PLASTIC-SPHERE
    PLASTIC-SPHERE
  • 8
    3233754 PIN-DOWEL
    PIN-DOWEL
  • 9
    3233644 PIN-DOWEL
    PIN-DOWEL
  • 10
    3233642 SPRING-DETENT
    SPRING-DETENT
  • 11
    3233060 BULLET,DETENT
    BULLET,DETENT
  • 12
    3233076 O-RING
    O-RING
  • 13
    3233639 SLIDE-LOW
    SLIDE-LOW
  • 14
    7546707 NUT, METRIC
    NUT, METRIC
  • 15
    7061014 ROD END,RH,6MM.
    ROD END,RH,6MM.
  • 16
    7546701 NUT
    NUT
  • 17
    7061013 ROD END,LH,6MM.
    ROD END,LH,6MM.
  • 18
    5020824 ROD,SHIFT LINKAGE,LOW RANGE
    ROD,SHIFT LINKAGE,LOW RANGE
  • 19
    5020823 ROD-SHIFT LINKAGE,HI RANGE
    ROD-SHIFT LINKAGE,HI RANGE
  • 20
    7546702 NUT
    NUT
  • 21
    3233640 SLIDE-HIGH/REV
    SLIDE-HIGH/REV
  • 22
    3233641 GEAR,SELECTOR,BODY
    GEAR,SELECTOR,BODY
  • 23
    3233643 SPRING-CENTERING
    SPRING-CENTERING
  • 23
    1341271 SELECTOR ASM,GEAR (INCL. 1-13,21-23)
    SELECTOR ASM,GEAR (INCL. 1-13,21-23)
