OIL COOLING SYSTEM для Polaris MAGNUM 325 2X4 (A01CB32AA) - 2001 года выпуска

  • №
    Артикул
    Название
  • 1
    5412039 HOSE, COOLER SWIVEL (9/16'' 90Ш) (BUILT BEFORE 1/01/01)
    HOSE, COOLER SWIVEL (9/16'' 90Ш) (BUILT BEFORE 1/01/01)
  • 1
    5412039 HOSE, COOLER SWIVEL (9/16'' 90Ш) ( BUILT AFTER 1/01/01)
    HOSE, COOLER SWIVEL (9/16'' 90Ш) ( BUILT AFTER 1/01/01)
  • 2
    7080862 CLAMP, HOSE MUBEA
    CLAMP, HOSE MUBEA
  • 3
    7542122 NUT, LOCK
    NUT, LOCK
  • 4
    5243783-067 BRACKET, OIL COOLER (TOP/BLACK)
    BRACKET, OIL COOLER (TOP/BLACK)
  • 5
    7080869 CLAMP-P, CUSHIONED (1.25'' I.D.)
    CLAMP-P, CUSHIONED (1.25'' I.D.)
  • 6
    7515158 SCREW
    SCREW
  • 7
    7517659 SCREW
    SCREW
  • 8
    2410157 FAN, MOTOR
    FAN, MOTOR
  • 9
    7670111 CLIP-U, ZY
    CLIP-U, ZY
  • 10
    5433353 SHROUD, FAN
    SHROUD, FAN
  • 11
    4010274 THERMISTER
    THERMISTER
  • 12
    7052296 VALVE, PLASTIC RAD/COOLER DRAIN
    VALVE, PLASTIC RAD/COOLER DRAIN
  • 13
    1240074 COOLER, OIL
    COOLER, OIL
  • 14
    5411548 MOUNT, RUBBER
    MOUNT, RUBBER
  • 15
    1013302 BRACKET, OIL COOLER ASSY. (LOWER)
    BRACKET, OIL COOLER ASSY. (LOWER)
  • 16
    7080866 CLAMP, HOSE MUBEA (1/2'')
    CLAMP, HOSE MUBEA (1/2'')
  • 17
    5412038 HOSE, COOLER SWIVEL (3/4'' 90Ш) (BUILT BEFORE 1/01/01)
    HOSE, COOLER SWIVEL (3/4'' 90Ш) (BUILT BEFORE 1/01/01)
