SUSPENSION - FRONT A - ARM W/ TIE RODS для Polaris TRAIL BOSS (A00AA32AA) (WHITE) - 2000 года выпуска
-
№АртикулНазвание
-
17542403 NUT, LOCKNUT, LOCK
-
25333367 BUSHINGBUSHING
-
35411291 SEAL, BOOT ROD END (1/2 IN)SEAL, BOOT ROD END (1/2 IN)
-
47061034 ROD, END (RIGHT)ROD, END (RIGHT)
-
57542711 NUT, JAMNUT, JAM
-
65020927 ROD, TIEROD, TIE
-
77547028 NUT, JAM (LEFT)NUT, JAM (LEFT)
-
87061033 ROD END KIT (OUTER) (BUILT BEFORE 8/16/99)ROD END KIT (OUTER) (BUILT BEFORE 8/16/99)
-
87061054 ROD, END (10MM/42 DEGREE) (BUILT AFTER 8/16/99)ROD, END (10MM/42 DEGREE) (BUILT AFTER 8/16/99)
-
91820566 TIE ROD KIT (INCL. 3-8) (IF BUILT BEFORE 8/16/99)TIE ROD KIT (INCL. 3-8) (IF BUILT BEFORE 8/16/99)
-
91820806 TIE, ROD ASSY. (1/2-20X14.0) (INCL. 3-8) (BUILT AFTER 8/16/99)TIE, ROD ASSY. (1/2-20X14.0) (INCL. 3-8) (BUILT AFTER 8/16/99)
-
107555806 WASHER (BUILT BEFORE 8/16/99)WASHER (BUILT BEFORE 8/16/99)
-
107556099 WASHER (BUILT AFTER 8/16/99)WASHER (BUILT AFTER 8/16/99)
-
117546904 NUT, CASTLENUT, CASTLE
-
127661203 PIN, COTTERPIN, COTTER
-
135240717 BRACKET, BALL JOINTBRACKET, BALL JOINT
-
147512284 BOLT, SOCKETBOLT, SOCKET
-
157542438 NUT, CASTLENUT, CASTLE
-
165410548 BOOT, RUBBERBOOT, RUBBER
-
177080673 JOINT, BALLJOINT, BALL
-
195431596 BUSHING, A-ARM LONG (BLACK)BUSHING, A-ARM LONG (BLACK)
-
205020677 BUSHING, A-ARM SPACERBUSHING, A-ARM SPACER
-
217080433 FITTING, ZERK THREADEDFITTING, ZERK THREADED
-
222201523 A-FRAME KIT (LEFT) (INCL. 19-21,24,25)A-FRAME KIT (LEFT) (INCL. 19-21,24,25)
-
222201524 A-FRAME KIT (RIGHT) (INCL. 19-21,24,25)A-FRAME KIT (RIGHT) (INCL. 19-21,24,25)
-
235020681 SHAFT, A-ARMSHAFT, A-ARM
-
247512492 SCREWSCREW
-
257552603 WASHERWASHER
-
267517527 BOLTBOLT
